Harry Fittings, located in Houston, USA, stands out as a top manufacturer and supplier of high-quality SMO 254 forged fittings, specifically crafted for demanding applications in harsh, corrosive, and high-pressure settings. SMO 254 is a premium austenitic stainless steel renowned for its remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking caused by chlorides. Harry Fittings offers a comprehensive selection of forged fittings, including elbows, tees, couplings, unions, and plugs, all adhering to ASME, ASTM, and ANSI standards. With their exceptional durability, strength, and corrosion resistance, SMO 254 forged fittings from Harry Fittings are perfect for offshore, marine, chemical, and desalination industries.
| 254 Forged Fittings Specifications | ASTM A182/ ASME SA182 |
|---|---|
| 254 SMO Forged Fittings size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| 6 Moly Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| SMO 254 Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM A182 SMO 254 Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| SMO 254 Forged Fittings Thread | NPT, BSPT, BSPP |
| SMO 254 Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SMO 254 Forged Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| Grade | Ni | Cr | Mo | Cu | N | C | Mn | Si | P | S |
| SMO 254 | 17.5 – 18.5 | 19.5 – 20.5 | 6 – 6.5 | 0.5 – 1 | 0.18 – 0.22 | 0.02 max | 1 max | 0.8 max | 0.03 max | 0.01 max |
| Density | Melting Point | Tensilee Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1320-1390 ℃ | 650 | 300 | 35 % |
SMO 254 forged fittings from Harry Fittings are made up of 19.5–20.5% chromium, 17.5–18.5% nickel, and 6–6.5% molybdenum, along with added nitrogen and copper to boost their resistance to aggressive chloride-rich environments. These fittings boast impressive tensile strength (~650 MPa), yield strength (~300 MPa), and outstanding elongation and toughness, even in high-temperature or corrosive situations. Produced in line with ASTM A182 F44, SMO 254 forged fittings undergo rigorous testing for dimensional accuracy, impact strength, and corrosion performance, ensuring they provide reliable service in demanding systems.
Harry Fittings is a leading supplier of SMO 254 Forged Fittings in Houston, USA. We offer an extensive range of SMO 254 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
| SMO 254 | 1.4547 | S31254 | SIS 2378 | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
| ASTM A182 / A182M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic SMO Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | SMO fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
Choose SMO 254 Forged Fittings from Harry Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
SMO 254 Forged Fittings offer many advantages, including exceptional corrosion resistance, especially in high chloride environments, making them ideal for marine, chemical and petrochemical applications Their high molybdenum and chromium content pitting, cracking corrosion and stress corrosion cracks Provides excellent strength for . These fittings also exhibit good strength and durability, ensuring high tensile strength and yield strength, long-term performance in harsh conditions Furthermore, SMO 254 mesh fittings offer excellent weldability and formability, making them versatile for a wide range of industrial applications, providing reliability and cost – efficiency.
Yes, custom sizes for SMO 254 Forged Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us
SMO 254 forged fittings from Harry Fittings find extensive use in desalination plants, offshore oil and gas platforms, chemical processing systems, pulp and paper bleaching operations, and seawater cooling systems. Their exceptional resistance to pitting, crevice corrosion, and chloride stress corrosion makes them particularly suitable for marine and high-salinity environments. Common applications include pumps, heat exchangers, pressure vessels, and pipeline connectors in challenging service conditions.
