Hastelloy C22 Pipe Fittings

Harry Fittings, located in Houston, USA, stands out as a top manufacturer and supplier of Hastelloy C22 pipe fittings. These fittings are celebrated for their remarkable resistance to corrosion and high-performance capabilities, making them perfect for demanding industries like chemical processing, marine, and pharmaceuticals. Each piece is crafted with precision and meets international quality standards, ensuring that Harry Fittings’ Hastelloy C22 products are both reliable and durable. By prioritizing innovation and customer satisfaction, we’ve earned a reputation as a trusted partner for high-quality pipe fitting solutions across various industrial applications.

Hastelloy C22 Stub End In USA, Hastelloy C22 Buttweld Elbow United kingdom, ASTM B366 Hastelloy Alloy C22 Pipe Fittings Houston, Hastelloy C22 Reducing Tee Los Angeles, Hastelloy® C22 Pipe Fittings in Houston, ASME SB366 Hastelloy® Alloy C22 Pipe Cap Texas, Hastelloy C22 Buttweld Fittings California.

Hastelloy C22 Pipe Fittings Specification

Specification : ASTM B366 / ASME SB366

Dimension Standard : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43

ASME B16.9 : standard for – Factory-Made Wrought Buttwelding Fittings

ASME B16.25 : Buttwelding Ends

ASME B16.28 : standard for – Butt-Welded Short Radius Elbows & Returns Bends

MSS SP-43 : Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

Size Range : ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)

Seamless Butt Weld Fitting Size : 1/2″ – 10″

Welded Butt Weld Fittings Size : 1/2″ – 48″

Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Type : Seamless / Welded / Fabricated

Hastelloy C22 is a nickel-chromium-molybdenum alloy that also includes iron and tungsten. It boasts outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking. With a tensile strength reaching up to 690 MPa and excellent ductility, Hastelloy C22 pipe fittings excel in high-stress environments. They maintain their mechanical integrity over a wide temperature range, making them ideal for tough applications. Their corrosion-resistant features make them particularly well-suited for handling both oxidizing and reducing agents in harsh chemical settings.

Hastelloy C22 Pipe Fittings Chemical Composition

Grade	C	Mn	Si	S	Co	Ni	Cr	Fe	Mo	P
Alloy C22	0.010 max	0.50 max	0.08 max	0.02 max	2.50 max	50.015 min*	20.00 – 22.50	2.00 – 6.00	12.50 – 14.50	0.02 max

Hastelloy C22 Pipe Fittings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Hastelloy C22	8.69 g/cm3	1399 °C (2550 °F)	Psi – 1,00,000 , MPa – 690	Psi – 45000 , MPa – 310	45 %

Equivalent Grades for Hastelloy C22 Pipe Fittings

STANDARD	UNS	WERKSTOFF NR.	JIS	EN
Hastelloy C22	N06022	2.4602	NW 6022	NiCr21Mo14W

Hastelloy C22 45 deg. Elbow In USA, Hastelloy C22 Reducer United kingdom, Hastelloy C22 90 deg Elbow Houston, ANSI B16.9 Hastelloy C22 Buttweld Pipe Fittings Suppliers in Los Angeles, Hastelloy C22 Pipe Bend in Houston, Hastelloy® C22 Pipe Fittings Price List in Texas, Hastelloy C22 Pipe Elbow Suppliers California, Hastelloy C22 Seamless Pipe Fittings USA.

Largest Hastelloy C22 Pipe Fittings Supplier in Houston, USA

Harry Fittings is a leading supplier of Hastelloy C22 Pipe Fittings in Houston, USA. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Hastelloy C22 Pipe Fittings Dimensions

Nominal Pipe Size	All Fittings	All Fittings	All Fittings	Elbows/ Tees	180° Return Bends	180° Return Bends	180 Deg Return Bends	Reducers	Caps
NPS	O.D. at Bevel (1), (2)	I.D. at End (1), (3), (4)	Wall Thickness (3)	Centre-to-End Dimension A,B,C,M	Centre-to-Centre O	Back-to-Face K	Alignment of Ends U	Overall Length H	Overall Length E
½ to 2½	0.06 -0.03	0.03	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
3 to 3 ½	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
4	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
5 to 8	0.09 -0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.25
10 to 18	0.16 -0.12	0.12	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
20 to 24	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
26 to 30	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.12	…	…	…	0.19	0.38
32 to 48	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.19	…	…	…	0.19	0.38

Why Choose Hastelloy C22 Pipe Fittings from Harry Fittings?

Hastelloy C22 Pipe Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Hastelloy C22 Buttweld Cross Manufacturers USA, Hastelloy C22 Welded Pipe Fittings Exporter in United kingdom, Hastelloy C22 Elbow Houston, ASTM B366 Hastelloy C22 Tee Los Angeles, ASME SB366 Hastelloy C22 Unequal Tee Houston, Hastelloy® C22 Straight Tees Texas, ASME / ANSI B16.9 Hastelloy C22 Short Stub End California.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Hastelloy C22 pipe fittings offer exceptional resistance to corrosion, particularly in oxidizing and reducing environments, making them ideal for chemical processing. They withstand high temperatures and aggressive chemicals, including chlorides, acids, and oxidizing agents, enhancing durability in extreme conditions. Their superior weldability and machinability ensure ease of fabrication. With excellent resistance to pitting, crevice corrosion, and stress corrosion cracking, they maintain structural integrity in demanding applications. These fittings are versatile, suitable for pharmaceutical, marine, and power industries, ensuring long-term reliability, reduced maintenance, and cost-efficiency in critical environments.

Types of Hastelloy C22 Pipe Fittings

Are Custom Sizes Available for Hastelloy C22 Pipe Fittings?

Yes, custom sizes for Hastelloy C22 Pipe Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.

Hastelloy C22 45 deg. Elbow In USA, Hastelloy C22 Reducer United kingdom, Hastelloy C22 90 deg Elbow Houston, ANSI B16.9 Hastelloy C22 Buttweld Pipe Fittings Suppliers in Los Angeles, Hastelloy C22 Pipe Bend in Houston, Hastelloy® C22 Pipe Fittings Price List in Texas, Hastelloy C22 Pipe Elbow Suppliers California, Hastelloy C22 Seamless Pipe Fittings USA.

Application Industry of Hastelloy C22 Pipe Fittings

Hastelloy C22 pipe fittings are widely utilized in industries that demand strong resistance to highly corrosive environments. This includes chemical processing plants that deal with acids and oxidizing agents, marine applications that need to withstand saltwater corrosion, and flue gas desulfurization systems. They’re also commonly found in the pharmaceutical and food processing sectors for hygienic fluid transport. Furthermore, Hastelloy C22 is a go-to choice for heat exchangers, reactors, and scrubbers where exposure to aggressive chemicals is a regular occurrence. Its versatility and durability ensure efficient operation in critical and challenging environments.
