45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow

Harry Fittings is a top-notch manufacturer and supplier located in Houston, USA, known for its high-quality pipe fittings, including both 45 Degree Long Radius and 45 Degree Short Radius Elbows. With a solid reputation for precision engineering and durability, Harry Fittings offers a range of standard and custom solutions tailored to meet various industrial needs. Their elbows are commonly used in piping systems to facilitate efficient directional changes while keeping pressure loss to a minimum. The company is dedicated to quality and customer satisfaction, serving key sectors like oil & gas, petrochemical, power generation, and construction, both domestically and internationally.

45 Deg Long Redius Elbow Price List in Houston, Stainless Steel 45 Deg Short Redius Elbow Supplier in Houston, ANSI/ASME B16.9 45 Deg Short Redius Elbow Exporter in Los Angeles, SS 45 Deg Long Redius Elbow/ 45 Deg Short Redius Elbow Supplier in Los Angeles, Carbon Steel 45 Deg Long Redius Elbow Exporter in Texas, Alloy Steel ASME B16.25 45 Deg Short Redius Elbow Size Chart, ANSI B19.28 45 Deg Long Redius Elbow Price in California, MSS-SP-43 45 Deg Short Redius Elbow in Houston, Duplex Steel 45 Deg Short Redius Elbow Supplier in Texas, Nickel Alloy 45 Deg Long Redius Elbow Stockist in Houston, Low Temperature Carbon Steel 45 Deg Short Redius Elbow Exporter in USA

45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow Specification

Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.

DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011

EN : EN10253-1, EN10253-2

Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS

Type : Seamless / ERW / Welded / Fabricated

Seamless 45° Long Radius Elbow Size: 1/2″~24″

ERW / Welded / Fabricated 45° Long Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)

Form: 45° Long Radius Elbow

The 45 Degree Long Radius and Short Radius Elbows from Harry Fittings are made from top-grade materials such as stainless steel, carbon steel, and alloy steel, ensuring excellent corrosion resistance and strength. These fittings boast impressive mechanical properties, including high tensile strength, good elongation, and resistance to wear and impact. The long radius design allows for smoother flow, while the short radius version is perfect for tight spaces, maintaining structural integrity even under high pressure and temperature conditions. Plus, these elbows meet international standards, guaranteeing reliability and performance in demanding applications.

45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow Material & Grades

Stainless Steel 45° Long Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L

Carbon Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.

Alloy Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91

Duplex Steel 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205

Super Duplex 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950

Nickel Alloy 45° Long Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.

Low Temperature Carbon Steel 45° Long Radius Elbow : ASTM A420 WPL3, A420 WPL6

Low Temperature Carbon Steel 45 Deg Short Redius Elbow Exporter in USA, 45 Deg Long Redius Elbow/ 45 Deg Short Redius Elbow Price List in Houston, Stainless Steel 45 Deg Long Redius Elbow Supplier in Houston, ANSI/ASME B16.9 45 Deg Short Redius Elbow Exporter in Los Angeles, Alloy Steel 45 Deg Long Redius Elbow/ 45 Deg Short Redius Elbow Exporter in Texas, ASME B16.9 45 Deg Short Redius Elbow in California, MSS-SP-43 45 Deg Short Redius Elbow Size Chart, Alloy Steel ASME B16.25 Price in California, Pipe Fittings 45 Deg Short Redius Elbow Manufacturer Weight Chart, Fitting 45 Deg Long Redius Elbow/ 45 Deg Short Redius Elbow Supplier in Texas, Stainless Steel 45 Deg Long Redius Elbow Stockist in Houston.

Largest 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow Supplier in Houston, USA

Harry Fittings is a leading supplier of 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow in Houston, USA. We offer an extensive range of 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Why Choose 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow from Harry Fittings?

Choose 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow from Harry Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.

Stainless Steel 45 Deg Short Redius Elbow Exporter in Houston, Carbon Steel 45 Deg Long Redius Elbow in mm, Alloy Steel 45 Deg Short Redius Elbow Manufacturer in Los Angeles, Super Duplex 45 Deg Long Redius Elbow in Houston, Nickel Alloy 45 Deg Long Redius Elbow, Low Temperature Carbon Steel 45 Deg Long Redius Elbow Supplier in Houston, ANSI/ASME B16.9 45 Deg Short Redius Elbow Price List in Texas, SS 45 Deg Long Redius Elbow Distributor in Texas, Alloy Steel ASME B16.25 45 Deg Long Redius Elbow/ 45 Deg Short Redius Elbow Supplier in Los Angeles, Pipe Fittings 45 Deg Short Redius Elbow Distributor in USA.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

45° Long Radius and 45° Short Radius Elbows offer distinct advantages depending on application needs. The Long Radius Elbow provides a gradual, smooth bend, ensuring minimal pressure loss and efficient flow, making it ideal for high-velocity systems. It is commonly used in larger piping setups. The Short Radius Elbow, on the other hand, is perfect for compact installations with limited space, offering quick directional changes. Both types are highly durable, corrosion-resistant, and made from strong materials like stainless steel, ensuring long-lasting performance in industries such as oil and gas, HVAC, and chemical processing.

Types of 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow

Are Custom Sizes Available for 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow?

Yes, custom sizes for 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.

Are Custom Sizes Available for 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow?

NPS	O.D. D	90 degrees Long Radius Center-to-End A	45 degrees Long Radius Center-to-End B	90 degrees 3D Center-to-End A	45 degrees 3D Center-to-End B
1/2	21.3	38	16	–	–
3/4	26.7	38	19	57	24
1	33.4	38	22	76	31
1 ¼	42.2	48	25	95	39
1 ½	48.3	57	29	114	47
2	60.3	76	35	152	63
2 ½	73	95	44	190	79
3	88.9	114	51	229	95
3 ½	101.6	133	57	267	111
4	114.3	152	64	305	127
5	141.3	190	79	381	157
6	168.3	229	95	457	189
8	219.1	305	127	610	252
10	273	381	159	762	316
12	323.8	457	190	914	378
14	355.6	533	222	1067	441
16	406.4	610	254	1219	505
18	457	686	286	1372	568
20	508	762	318	1524	632
22	559	838	343	1676	694
24	610	914	381	1829	757
26	660	991	406	1981	821
28	711	1067	438	2134	883
30	762	1143	470	2286	964
32	813	1219	502	2438	1010
34	864	1295	533	2591	1073
36	914	1372	565	2743	1135
38	965	1448	600	2896	1200
40	1016	1524	632	3048	1264
42	1067	1600	660	3200	1326
44	1118	1676	695	3353	1389
46	1168	1753	727	3505	1453
48	1219	1829	759	3658	1516

45 Deg Short Redius Elbow Supplier in Houston, Stainless Steel 45 Deg Long Redius Elbow/ 45 Deg Short Redius Elbow Weight Chart, Carbon Steel 45 Deg Short Redius Elbow Exporter in Houston, Alloy Steel 45 Deg Long Redius Elbow Manufacturer in Los Angeles, Duplex Steel 45 Deg Short Redius Elbow Price List in Texas, Super Duplex 45 Deg Long Redius Elbow/ 45 Deg Short Redius Elbow Sizes in mm, Nickel Alloy 45 Deg Short Redius Elbow Distributor in Texas, Low Temperature Carbon Steel 45 Deg Long Redius Elbow/ 45 Deg Short Redius Elbow Distributor in USA.

Application Industry of 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow

Both the 45 Degree Long Radius and Short Radius Elbows are crucial components in piping systems, allowing for changes in flow direction while keeping turbulence to a minimum. Long radius elbows are typically used in systems that require lower friction and pressure drops, making them ideal for chemical plants and refineries. On the other hand, short radius elbows are favored in installations where space is limited, such as shipbuilding and compact industrial layouts. Both types are extensively used in oil & gas, power plants, water treatment facilities, and HVAC systems, where reliability, strength, and efficient flow dynamics are essential for operational efficiency and safety.
