Harry Fittings is a top-notch manufacturer and supplier located in Houston, USA, focusing on high-quality Long Radius and Piggable Bends for a variety of industrial uses. We pride ourselves on our commitment to engineering excellence, delivering precision-engineered fittings that stand up to the toughest standards of durability and performance. Our facility boasts cutting-edge technology and a team of skilled professionals dedicated to crafting each product to exact specifications. Whether it’s for the oil and gas sector, petrochemical industry, or water treatment facilities, Harry Fittings is your go-to source for reliable solutions that meet demanding operational needs, all backed by outstanding service and prompt delivery across the USA and beyond.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Size: 1/2″–60″
Form: Long Radius Bend, Induction Bend, With R=3D, 5D, 6D, 8D, 10D & Customized Bend
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Size Range : 2″NB TO 18″ NB ANSI B 16.9 IN
Form: Piggable Bends
At Harry Fittings, we create Long Radius and Piggable Bends using top-quality materials like stainless steel, carbon steel, and alloy steels, carefully chosen based on the specific application requirements. These bends are designed to offer impressive mechanical properties, including high tensile strength, corrosion resistance, and impact toughness. Built for long-lasting durability, they maintain their structural integrity even under extreme pressures and temperatures. Our products adhere to ASTM, ASME, and ANSI standards, ensuring they are dependable in critical pipeline systems. Through precision forming and heat treatment processes, we enhance the grain structure and optimize mechanical performance, making our fittings perfect for high-demand industries.
Harry Fittings is a leading supplier of Long Redius and Piggable Bend in Houston, USA. We offer an extensive range of Collar, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Long Redius and Piggable Bend from Harry Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Long Radius and Piggable Bends offer several key advantages, including smooth internal surfaces that minimize flow turbulence and reduce pressure drops in pipeline systems. Their gentle curves ensure a more efficient flow of fluids, enhancing overall system performance. The durability and resistance to corrosion, heat, and pressure, especially in materials like stainless steel and alloy steel, extend the lifespan of the fittings. Additionally, their ability to accommodate pigs (cleaning tools) ensures easier maintenance and reduces the risk of blockages, making them ideal for complex and demanding piping applications.
Yes, custom sizes for Long Redius and Piggable Bend are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.
Stainless Steel Long Radius Bend : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel Long Radius Bend : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel Long Radius Bend : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel Long Radius Bend : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex Long Radius Bend : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy Long Radius Bend : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel Long Radius Bend : ASTM A420 WPL3, A420 WPL6
Stainless Steel Piggable Bend : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel Piggable Bend : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel Piggable Bend : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel Piggable Bend : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex Piggable Bend : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy Piggable Bend : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel Piggable Bend : ASTM A420 WPL3, A420 WPL6
| Nominal PN (MPa) | DN | Thread D | Pipe Specification DH×s | L1 | L2 | L3 (Not less than) | L (Not less than) | R |
| 32.0 | 175 | M240×6 | 245×36 | 120 | 130 | 360 | 1095 | 735 |
| 200 | M265×6 | 273×40 | 130 | 140 | 390 | 1209 | 819 | |
| 225 | M320×6 | 325×50 | 175 | 185 | 525 | 1500 | 975 | |
| 250 | M350×6 | 355.6×55 | 195 | 205 | 580 | 1650 | 1070 | |
| 22.0 | 175 | M215×6 | 219×24 | 100 | 110 | 300 | 957 | 657 |
| 200 | M240×6 | 245×26 | 110 | 120 | 330 | 1065 | 735 | |
| 225 | M265×6 | 273×29 | 115 | 125 | 345 | 1164 | 819 | |
| 250 | M295×6 | 299×32 | 120 | 130 | 360 | 1257 | 897 |
Long Radius and Piggable Bends are crucial in pipeline systems where smooth directional changes are necessary without disrupting flow dynamics. These fittings find extensive use in oil and gas, petrochemical, power generation, water treatment, and food processing sectors. Their design allows for straightforward pigging operations, making internal cleaning and inspection of pipelines a breeze, which helps minimize downtime and boosts operational efficiency. Long Radius bends are particularly effective at reducing turbulence and pressure drop, ultimately extending the lifespan of the pipeline system. At Harry Fittings, we offer custom solutions tailored to meet your specific needs.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
