Harry Fittings is a well-respected manufacturer and supplier of Alloy 20 Buttweld Fittings, proudly based in Houston, USA. They’ve built a solid reputation for providing top-notch products that cater to the varied needs of different industries. With years of expertise and state-of-the-art production facilities, the company specializes in precision-engineered fittings that meet international standards. Their Alloy 20 Buttweld Fittings are particularly valued for their outstanding resistance to corrosion, especially in chemical and acidic settings. Harry Fittings is committed to timely deliveries, competitive pricing, and exceptional customer service, making them a reliable partner for clients in the chemical, petrochemical, and marine sectors.
| 20 Pipe Fittings Specifications | ASTM B366/ ASME SB366 |
|---|---|
| Alloy 20 Pipe Fittings size | 20 Seamless Butt Weld Fittings : 1/2″ – 10″ 20 Welded Butt Weld Fittings : 1/2″ – 48″ |
| Alloy 20 Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Alloy 20 Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| 20 Buttweld Pipe FittingsType | DN15-DN1200 |
| ASTM B366 20 Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM B366 Alloy 20 Pipe Fitting |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM B366 20 Buttweld Fitting |
| ASTM B366 20 Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| Alloy 20 Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SA 366 20 Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | Alloy UNS N08020, 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
Alloy 20 Buttweld Fittings are primarily made up of nickel, chromium, iron, and copper, with added molybdenum and niobium to boost corrosion resistance. This special blend is effective against sulfuric acid corrosion and pitting. On the mechanical side, Alloy 20 boasts impressive tensile strength, flexibility, and durability. It typically shows a tensile strength of 80 ksi (552 MPa) and a yield strength of 35 ksi (241 MPa), along with good elongation properties, making it ideal for high-stress situations. These characteristics allow the fittings to maintain their structural integrity under pressure and varying temperatures.
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
Harry Fittings is a leading supplier of Alloy 20 Buttweld Fittings in Houston, USA. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
Alloy 20 Buttweld Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Alloy 20 Buttweld Fittings offer several key advantages, making them ideal for demanding applications. Their exceptional corrosion resistance, particularly to sulfuric acid and other aggressive chemicals, ensures long-lasting durability in harsh environments. Alloy 20 provides excellent mechanical properties, such as high strength, enhanced stress corrosion cracking resistance, and superior weldability. These fittings are highly resistant to pitting and crevice corrosion, making them ideal for industries like chemical processing, pharmaceuticals, and food processing. Their reliability and performance in extreme conditions reduce maintenance costs and extend the lifespan of piping systems.
| Standard Code | Standard Name |
| ANSI ASME SA-366 | Forged Durimet pipe fittings |
| ANSI ASME B16.9 | Factory-Made wrought steel pipe fittings |
| ANSI ASME B16.28 | Wrought steel butt-welding short radius elbows and returns |
| ISO 5251 | Alloy butt-welding fittings |
| MSS SP-43 | Wrought Alloy butt-welding fittings |
| MSS SP-75 | Forging butt-welding fittings |
| German Steel Pipe Fittings Standard | |
| DIN 2605 | Steel butt-welding pipe fittings.elbows and bends |
| DIN 2615 | Steel butt-welding pipe fittings.tees |
| DIN 2616 | Steel butt-welding pipe fittings.reducers |
| DIN 2617 | Steel butt-welding pipe fittings.caps |
| Japanese Steel Pipe Fittings Standard | |
| JIS B2311 | Universal steel butt-welding pipe fittings |
| JIS B2312 | Steel butt-welding pipe fittings |
| JIS B2313 | Steel plate butt-welding pipe fittings |
| Other Steel Pipe Fittings Standard | |
| EN 1025 | 3 Butt-welding pipe fittings |
Yes, custom sizes for Alloy 20 Buttweld Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.
You’ll find Alloy 20 Buttweld Fittings in applications that require exceptional resistance to acidic and corrosive environments. They’re commonly used in industries like chemical processing, pharmaceuticals, food and beverage, and power generation, proving particularly effective in handling sulfuric acid and chloride-containing solutions. Their durability and resistance to stress corrosion cracking make them perfect for heat exchangers, piping systems, storage tanks, and reactors. In marine and offshore applications, they deliver reliable performance and safety, even in tough environmental conditions and fluctuating temperatures.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
