Harry Fittings is a Houston-based, reliable manufacturer of high-performance Stainless Steel 304 Pipe Fittings. Famed for their strength, resistance to corrosion, and engineering excellence, Harry Fittings‘ range of pipe fittings finds extensive use in various industries like oil & gas, petrochemical, manufacturing, and construction. With the help of the latest manufacturing technologies and rigorous quality checks, Harry Fittings ensures every product upholds international performance levels. Whether you require conventional or bespoke fittings, the business delivers assured and effective solutions based on the particular needs of local and overseas customers, supported by a rigorous dedication to quality and customer satisfaction.
Specifications : ASTM A403 / ASME SA403
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Type : Seamless / Welded / Fabricated
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Stainless Steel 304 Pipe Fittings consist of 18–20% Chromium and 8–10.5% Nickel, together with minute traces of Carbon, Manganese, and Silicon. Austenitic chromium-nickel steel, this material provides excellent resistance to corrosion, especially in weakly acidic and oxidizing environments. These fittings have a tensile strength of ~515 MPa, yield strength of ~205 MPa, and elongation of ~40%. They are non-magnetic in nature, have good thermal strength, and show excellent weldability and machinability, making them very well-suited for critical operations within industries like pharmaceutical, food processing, marine, and general fabrication.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| 304 | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0-20.0 | – | 8.0-10.5 | 0.10 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304 | 515 | 205 | 40 | 92 | 201 |
Harry Fittings one of the largest suppliers of Stainless Steel 304 Pipe Fittings in Houston, USA. We specialize in providing a wide range of high-quality, durable fittings for various industrial applications. Our inventory includes elbows, tees, reducers, couplings, and other essential fittings designed to offer exceptional corrosion resistance and strength. Stainless Steel 304 is known for its cost-effectiveness and excellent mechanical properties, making it ideal for industries such as construction, chemical processing, and food processing. With a commitment to customer satisfaction, timely delivery, and competitive pricing, we are the trusted choice for Stainless Steel 304 Pipe Fittings in the USA.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 304 Pipe Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| SS 304 | S30400 | 1.4301 | Z7CN18‐09 | X5CrNi18-10 | SUS 304 | 304S31 | 08Х18Н10 |
| Nominal Pipe Size | Outside Diameter | 90° Elbows | 45° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
(inches) | Long Radius | Short Radius | Long Radius | Long Radius | ||||
(mm) | (inches) | Center to Face (inches) | Center to Face (inches) | Center to Face (inches) | Radius (inches) | Center to Center (inches) | Back to face (inches) | |
1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
3/4 | 26.7 | 1.050 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
Stainless steel 304 pipe fittings provide excellent corrosion resistance, making them ideal for use in harsh environments and applications such as chemical processing and food processing Their high strength ensures it works longer, and reduces maintenance costs. They exhibit high strength and resist high temperatures, making them suitable for complex applications. These features are easy to assemble and manufacture, allowing for efficient installation. In addition, their smooth surface reduces contamination and aids cleaning properties. The cost-effective and versatile SS 304 pipe fittings offer reliable performance in a variety of industries including marine, construction and chemical.
Yes, custom sizes are available for Stainless Steel 304 Pipe Fittings to meet specific requirements. We offer tailored solutions to ensure precise fit and performance for various applications. For more information, please contact us at sales@harryfittings.us.
| Density lbm/in3 | Thermal Conductivity (BTU/h ft. °F) | Electrical Resistivity (in x 10-6) | Modulus of Elasticity (psi x 106 | Coefficient of Thermal Expansion (in/in)/ °F x 10-6 | Specific Heat (BTU/lb/ °F) | Melting Range (°F) |
|---|---|---|---|---|---|---|
| SS 304/304L | ||||||
| at 68°F: 0.285 | 9.4 at 212°F | 28.3 at 68°F | 28 | 9.4 at 32 – 212°F | 0.1200 at 68°F to 212°F | 2500 to 2590 |
| 12.4 at 932 °F | 39.4 at 752°F | 10.2 at 32 – 1000°F | ||||
| 49.6 at 1652 °F | 10.4 at 32 – 1500°F | |||||
Stainless Steel 304 Pipe Fittings are used to a large extent because they are corrosion-resistant, can be formed, and are durable. They best suit chemical process units, water treatment plants, and food and beverage manufacturing, where safety and cleanliness are top priority. Their oxide resistance qualifies them to be used in oil and gas pipelines, marine installations, and chemical plants. 304 fittings are also used in HVAC applications, architectural structures, and pharmaceutical plants, based on their clean finish and mechanical strength. Their simplicity of manufacture and general chemical compatibility render them a suitable, versatile option for high-performance, durable industrial and commercial applications.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
