Our 90° Short Radius Elbows are made from robust materials such as stainless steel, carbon steel, and alloy steel, chosen based on the specific pressure and temperature needs. These elbows boast impressive mechanical properties, including high tensile strength, pressure resistance, and dimensional stability. Thanks to their short center-to-end distance, they’re perfect for installations in tight spaces where a quick change in direction is essential. Each elbow is manufactured in line with ASME B16.9 standards and goes through thorough testing and quality checks. The forging and heat treatment processes we employ enhance their toughness, ensure consistent wall thickness, and guarantee long-lasting performance in demanding piping conditions.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless Pipe 90° Short Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 90° Short Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 90° Short Radius Elbow
Our 90° Short Radius Elbows are made from robust materials such as stainless steel, carbon steel, and alloy steel, chosen based on the specific pressure and temperature needs. These elbows boast impressive mechanical properties, including high tensile strength, pressure resistance, and dimensional stability. Thanks to their short center-to-end distance, they’re perfect for installations in tight spaces where a quick change in direction is essential. Each elbow is manufactured in line with ASME B16.9 standards and goes through thorough testing and quality checks. The forging and heat treatment processes we employ enhance their toughness, ensure consistent wall thickness, and guarantee long-lasting performance in demanding piping conditions.
Stainless Steel 90° Short Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 90° Short Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 90° Short Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 90° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 90° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 90° Short Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 90° Short Radius Elbow : ASTM A420 WPL3, A420 WPL6
Harry Fittings is a leading supplier of 90 Deg Short Redius Elbow in Houston, USA. We offer an extensive range of 90 Deg Short Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose 90 Deg Short Redius Elbow from Harry Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
90° Short Radius Elbows provide several key advantages, including their ability to fit into compact spaces where standard long radius elbows may not be suitable. Their design allows for quick directional changes in piping systems, making them ideal for installations with limited room. Despite their tighter bend, these elbows offer reliable flow control and minimal pressure loss in low-velocity systems. Made from durable materials like stainless steel and alloys, they offer corrosion resistance and long-lasting performance. Widely used in industries such as HVAC, chemical processing, and plumbing, they ensure efficient and effective flow management.
Yes, custom sizes for 90 Deg Short Redius Elbow are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.
| NPS | O.D. D | Center-to-End A |
| 1 | 33.4 | 25 |
| 1 ¼ | 42.2 | 32 |
| 1½ | 48.3 | 38 |
| 2 | 60.3 | 51 |
| 2 ½ | 73 | 64 |
| 3 | 88.9 | 76 |
| 3 ½ | 101.6 | 89 |
| 4 | 114.3 | 102 |
| 5 | 141.3 | 127 |
| 6 | 168.3 | 152 |
| 8 | 219.1 | 203 |
| 10 | 273 | 254 |
| 12 | 323.8 | 305 |
| 14 | 355.6 | 356 |
| 16 | 406.4 | 406 |
| 18 | 457 | 457 |
| 20 | 508 | 508 |
| 22 | 559 | 559 |
| 24 | 610 | 610 |
You’ll find 90° Short Radius Elbows commonly used in compact piping systems where space is at a premium and sharp directional changes are necessary. They’re frequently utilized in oil refineries, chemical plants, shipbuilding, and power plants. These elbows efficiently redirect flow while preserving the pipeline’s structural integrity. Although their short radius design can lead to a higher pressure drop compared to long radius elbows, they are ideal for specific systems that require a minimal footprint. At Harry Fittings, we offer a wide range of sizes and material grades to ensure compatibility with complex piping layouts.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
