Inconel 718 Pipe Fittings Manufacturer and Supplier in Houston, USA

Harry Fittings, one of Houston, USA’s leading manufacturers and suppliers, is well known for its supply of superior quality pipe fittings catering to various industrial applications. With expertise in precision-engineered solutions, the company provides an extensive array of products, such as the tough Inconel 718 Pipe Fittings, meant for optimal performance under harsh conditions. Harry Fittings is committed to durability, innovation, and customer satisfaction and ensures every product adheres to high industry standards. Our Inconel 718 fittings are relied upon for their reliability, corrosion resistance, and extended service life, which makes us a go-to partner in industries such as aerospace, petrochemical, marine, and power generation.

ASTM B366 Alloy 718 Pipe Fittings Suppliers In USA, 718 Inconel Butt weld Pipe Fittings Exporter United kingdom, Inconel Alloy 718 Buttweld Fittings Houston, UNS N07718 Pipe Fittings Los Angeles, Nickel Alloy 718 Pipe Fittings Houston, Alloy 718 Industrial Pipe Fittings at Best Price Texas, Inconel 718 Pipe Fittings California, Alloy 718 Pipe Fittings Houston, USA.

Inconel 718 Pipe Fittings Specification

Specification :	ASTM B366, ASTM SB 366, ASTM B564, ASME SB564
Dimensions :	ANSI/ASME B16.9, B16.28, MSS-SP-43.
Size :	½”NB to 24″NB in Sch 10s, 40s, 80s, 160s, XXS.
Thickness :	Sch Sch 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160 Sch XXS
Types :	Seamless / ERW / Welded / Fabricated
Grades :	Inconel 718 – UNS N06600, Inconel 718 – UNS N06601 Inconel 718 – UNS N06625 Incoloy 800 – UNS N08800, Incoloy 800H / HT – UNS N08810, Incoloy 825 – UNS N08825

Inconel 718 Pipe Fittings consist of nickel (50–55%), chromium (17–21%), molybdenum (2.8–3.3%), and niobium (4.75–5.5%), while the remainder contains traces of iron, titanium, aluminum, and cobalt. This advanced alloy possesses superior oxidation and corrosion resistance when used in high-temperature applications. Inconel 718 has a tensile strength of 965 MPa, yield strength of 550 MPa, and excellent creep resistance up to 700°C. The material has a hardness value of about 250 HB and also shows excellent fatigue, stress rupture, and fracture toughness, thus being perfectly suitable for high-pressure, high-stress applications.

Inconel 718 Pipe Fittings Chemical Composition

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr	Al	Ti	Nb
718	0.08	0.35	0.35	0.01	0.3	bal	50.0 – 55.0	17.00 – 21.00	0.2 – 0.8	0.7 – 1.15	4.75 – 5.5

Inconel 718 Pipe Fittings Mechanical Properties

Grade	Density	Melting Point	Yield Strength (0.2%Offset)	Tensile Strength	Elongation
718	8.2 g/cm3	1350 °C (2460 °F)	Psi – 70,000 , MPa – 482	Psi – 1,35,000 , MPa -930	45 %

Inconel 2.4668 Pipe Fittings USA, ASME SB366 Nickel Alloy 718 Pipe Fittings Supplier in United kingdom, Inconel 718 90 Deg Elbow Houston, Inconel 718 Butt Weld LR Elbow Los Angeles, Alloy 718 Buttweld Tee Houston, Inconel® Alloy 718 Seamless Fittings In Texas, Inconel 718 Welded Fittings California, Uk,

Largest Inconel 718 Pipe Fittings Supplier in Houston, USA

Harry Fittings is a leading supplier of Inconel 718 Pipe Fittings in Houston, USA. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Inconel 718 Buttweld Fittings Equivalent

STANDARD	UNS	WERKSTOFF NR.	AFNOR
Inconel 718	N07718	2.4668	NC19FeNb

Why Choose Inconel 718 Pipe Fittings from Harry Fittings?

Inconel 718 Pipe Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Inconel 718 Pipe Fittings Dimensions Chart

Nominal Thickness (in) MM	Pipe Size (in)	Transverse Areas (in2) MM2			Diameter (in) MM		Volume (ft3/ft)	Number of Threads per inch of Screw	Weight		Length of Pipe (ft per sq.0 foot of surface)
Nominal Thickness (in) MM	Pipe Size (in)	Internal	External	Steel	Internal	External	Volume (ft3/ft)	Number of Threads per inch of Screw	(kg/m)	(lb/ft)	Internal Surface (ft)	External Surface (ft)
0.007	1/8	0.006	0.013	0.007	0.027	0.0405	0.00004	27	0.036	0.024	14.020	9.043
0.009	¼	0.010	0.023	0.013	0.036	0.0540	0.00007	18	0.063	0.042	10.049	7.007
0.009	3/8	0.019	0.036	0.017	0.049	0.0675	0.00013	18	0.084	0.057	7.075	5.066
0.011	½	0.030	0.055	0.025	0.062	0.0840	0.00021	14	1.026	0.085	6.014	4.055
0.011	¾	0.053	0.087	0.033	0.082	1.0050	0.00037	14	1.068	1.013	4.064	3.064
0.013	1	0.086	1.036	0.049	1.005	1.0315	0.00060	11 ½	2.050	1.068	3.064	2.090
0.014	1 ¼	1.050	2.016	0.067	1.038	1.0660	0.00104	11 ½	3.038	2.027	2.077	2.030
0.015	1 ½	2.004	2.084	0.080	1.061	1.0900	0.00141	11 ½	4.004	2.072	2.037	2.001
0.015	2	3.036	4.043	1.008	2.007	2.0375	0.00233	11 ½	5.043	3.065	1.085	1.061
0.020	2 ½	4.079	6.049	1.070	2.047	2.0875	0.00333	8	8.062	5.079	1.055	1.033
0.022	3	7.039	9.062	2.023	3.007	3.0500	0.00513	8	11.027	7.058	1.025	1.009
0.023	3 ½	9.089	12.056	2.068	3.055	4.0000	0.00687	8	13.056	9.011	1.008	0.095
0.024	4	12.073	15.090	3.017	4.003	4.0500	0.00884	8	16.006	10.079	0.095	0.085
0.026	5	20.000	24.030	4.030	5.005	5.0563	0.01389	8	21.074	14.061	0.076	0.069
0.028	6	28.089	34.047	5.058	6.007	6.0625	0.02006	8	28.023	18.097	0.063	0.058
0.032	8	50.002	58.042	8.040	7.098	8.0625	0.03552	8	42.049	28.055	0.048	0.044

ASME B36.10M Alloy 718 Pipe Schedule Chart

3 1/2″ IPS( 4.000″O. D.)	1/8″ IPS(.405″O. D.)
SCH 40, 10, 160, 80, XXH	SCH 40, 80
4″ IPS(4.500″O. D.)	1/4″ IPS(.540″O. D.)
SCH 40, 10, 160, 80, XXH	SCH 40, 10, 80
5″ IPS( 5.563″O. D.)	3/8″ IPS(.675″O. D.)
SCH 40, 10, 160, 80, XXH	SCH 40, 10, 80
6″ IPS(6.625″O. D.)	1/2″ IPS(.840″O. D.)
SCH 10, 5, 80, 40, 160, 120 XXH	SCH 5, 40, 10, 160, 80, XXH
8 ” IPS(8.625″O. D.)	3/4″ IPS(1.050″O. D.)
SCH 10, 5, 80, 40, 160, 120 XXH	SCH 40, 10, 160, 80, XXH
10″ IPS(10.750″O. D.)	1″ IPS:(1.315′O. D.)
SCH 10, 20, TRUE 80(.500), 40, 80 (.500),	SCH 5, 40, 10, 160, 80, XXH
12″ IPS(12.750″O. D.)	1-1/4″ IPS(1.660″O. D.)
SCH 10, 20, TRUE40(.406), 40(.375), SCH80(.500)	SCH 40, 10, 160, 80, XXH
14″ IPS(14.000″O. D.)	1-1/2″ IPS(1.900″O. D.)
SCH10(.188), SCH40(.375)	SCH 40, 10, 160, 80, XXH
16″ IPS(16.000″O. D.)	2″ IPS(2.375″O. D.)
SCH10(.188), SCH40(.375)	SCH 40, 10, 160, 80, XXH
18″ IPS (18.000″O. D.)	2 1/2″ IPS(2.875″O. D.)

Inconel 718 Reducer In USA, Alloy N07718 Butt weld Fittings United kingdom, Inconel 718 Butt weld Unequal Cross, 2.4668 Butt weld Pipe Fittings Houston, Inconel 718 End Pipe Cap Los Angeles, Alloy 718 Pipe Elbow Houston, ANSI B16.9 Inconel 718 Pipe Fittings ,Texas 718 Inconel SR Elbow California, Inconel 718 Pipe Nipple In USA, Inconel 718 Long Radius Bend United kingdom, Alloy 718 Stub End Stockist Los Angeles, Nickel Alloy 718 Two Joint Pipe Fittings Houston, Inconel 718 Butt weld Pipe Fittings Manufacturer in USA.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Inconel 718 Pipe Fittings offer numerous advantages, including exceptional resistance to corrosion, oxidation, and pitting, even in high-temperature and corrosive environments. Their high tensile and yield strength, along with superior creep-rupture properties, make them ideal for demanding applications. These fittings maintain stability and mechanical performance up to 700°C, making them suitable for aerospace, power generation, and chemical processing. Additionally, their weldability and ease of fabrication reduce installation challenges. Durable and reliable, Inconel 718 Pipe Fittings excel in extreme conditions, ensuring long service life and minimal maintenance requirements.

Types of Inconel 718 Pipe Fittings

Are Custom Sizes Available for Inconel 718 Pipe Fittings?

Yes, custom sizes for Inconel 718 Pipe Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.

Inconel 2.4668 Pipe Fittings USA, ASME SB366 Nickel Alloy 718 Pipe Fittings Supplier in United kingdom, Inconel 718 90 Deg Elbow Houston, Inconel 718 Butt Weld LR Elbow Los Angeles, Alloy 718 Buttweld Tee Houston, Inconel® Alloy 718 Seamless Fittings In Texas, Inconel 718 Welded Fittings California, Uk,

Application Industry of Inconel 718 Pipe Fittings

Inconel 718 Pipe Fittings find extensive use in applications that require higher strength, corrosion resistance, and heat stability. In the aerospace industry, they find application in jet engines, turbines, and exhaust systems where temperatures and pressures are extreme. Chemical and petrochemical processes depend upon these fittings to transport corrosive liquids and gases. They are a component of boilers, steam lines, and heat exchangers in power generation. Seawater corrosion resistance also renders them appropriate for use in marine and offshore platforms. Inconel 718’s exceptional characteristics provide long-term, satisfactory service in the most adverse environments.
