Harry Fittings, a top Houston, USA-based manufacturer and supplier, is a specialist in premium pipe fittings for various industrial uses. Known for precision engineering, high-quality products, and customer-centric service, Harry Fittings provides an extensive range of products designed to meet rigorous industry standards. Among its excellent products, the Inconel 625 Pipe Fittings are designed to perform exceptionally well under harsh conditions of high temperatures, corrosive chemicals, and mechanical stress. Relying on clients from industries such as aerospace, marine, chemical, and energy, Harry Fittings provides innovative, dependable, and durable solutions that guarantee operational excellence.
Standard :ASTM B366 / ASME SB366
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Type : Seamless / Welded / Fabricated
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Inconel 625 Pipe Fittings consist of a nickel-chromium-molybdenum alloy with an approximate composition of 58% nickel, 20–23% chromium, 8–10% molybdenum, and 3.15–4.15% niobium with minute traces of iron, manganese, and silicon. The alloy has excellent corrosion resistance, particularly in severe and oxidizing atmospheres. In a mechanical aspect, Inconel 625 offers a tensile strength of ~930 MPa, yield strength of ~414 MPa, and elongation of 30%, which holds up to cryogenic temperatures and up to 980°C. The thermal stability, creep resistance, and fatigue strength of the alloy make it perfect for harsh industrial uses.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 705 | 42.5 % |
Harry Fittings is a leading supplier of Inconel 625 Pipe Fittings in Houston, USA. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Pressure-Temperature ratings for Inconel 625 Pipe Fittings (psig) | |||||
|---|---|---|---|---|---|
| Temperature Ratings | Pressure Class | ||||
| 150 | 300 | ||||
| 1/4 – 1 inch. | 1 1/4 – 2 inch. | 2 1/2 – 3 inch. | |||
| (oF) | (oC) | ||||
| -20 to 150 | -29 to 66 | 300 | 2000 | 1500 | 1000 |
| 200 | 93 | 265 | 1785 | 1350 | 910 |
| 250 | 121 | 225 | 1575 | 1200 | 825 |
| 300 | 149 | 185 | 1360 | 1050 | 735 |
| 350 | 177 | 150 | 1150 | 900 | 650 |
| 400 | 204 | – | 935 | 750 | 560 |
| 450 | 232 | – | 725 | 600 | 475 |
| 500 | 260 | – | 510 | 450 | 385 |
| 550 | 288 | – | 300 | 300 | 300 |
Inconel 625 Pipe Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| DN (Normal Pipe Size) For ASME B16.9 | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Inconel 625 Pipe Fittings offer superior performance in challenging environments. Their outstanding corrosion and oxidation resistance make them ideal for marine, chemical, and aerospace industries. They withstand extreme temperatures, from cryogenic to 980°C, maintaining mechanical integrity. High tensile and yield strength eliminate the need for additional heat treatments. These fittings resist pitting, crevice corrosion, and stress-corrosion cracking, ensuring durability in acidic and saltwater conditions. Additionally, their excellent weldability and fabricability simplify installation, making them a reliable and cost-effective choice for high-performance applications across diverse industries.
Yes, custom sizes for Inconel 625 Pipe Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.
Inconel 625 Pipe Fittings are widely used in industries requiring high resistance against heat, pressure, and corrosion. In marine operations, they play a vital role in offshore oil and gas platforms, pipelines, and seawater systems because of their high resistance against saltwater corrosion. In the aerospace industry, they are used in jet engine exhaust systems, turbine blades, and afterburners, where temperature tolerance is important. Chemical processing facilities rely on these fittings to manage aggressive acids and solvents. Inconel 625 is also present in nuclear reactors, heat exchangers, and power plants, providing durability and safety under challenging operating conditions.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
