Houston, USA-based Harry Fittings is a prominent producer and supplier of high-quality pipe fittings suitable for the most stringent industrial uses. With its emphasis on precise engineering, endurance, and customer service, the company provides a wide variety of products that include Inconel 617 Pipe Fittings. These fittings are specifically designed to work well in high-temperature and corrosive conditions, so they find their uses in demanding applications across various industries. Relied on globally by clients, Harry Fittings supplies solutions of the highest international standards, providing long-term reliability and performance in aerospace, power generation, and chemical processing applications.
Specifications ASTM B366 / ASME SB366
Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, MSS SP-79
Size 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Type Seamless / Welded / Fabricated
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Thickness Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Grade Inconel 617 UNS (N06617), DIN (2.4663)
The Inconel 617 Pipe Fittings are fabricated from a high-temperature nickel-chromium-cobalt-molybdenum alloy. They contain about 50–60% nickel, 20–23% chromium, 12–15% cobalt, and minor amounts of molybdenum, aluminum, tungsten, and carbon. This alloy has superior resistance to carburization, oxidation, and high-temperature corrosion. Mechanically, Inconel 617 provides high tensile strength, very good creep resistance, and outstanding stress-rupture properties, holding strength at temperatures of up to 2000°F (1093°C). It possesses all these characteristics, which make it perfect for use in severe operations that involve thermal cycling, oxidative stress, and mechanical fatigue
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
Harry Fittings is a leading supplier of Inconel 617 Pipe Fittings in Houston, USA. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | UNS | WNR. |
| Alloy 617 | N06617 | 2.4663 |
Inconel 617 Pipe Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| NOMINAL PIPE SIZE | ALL FITTINGS | ALL FITTINGS | 180 DEG RETURN BENDS | REDUCERS | ELBOWS AND TEES | 180 DEG RETURN BENDS | CAPS |
|---|---|---|---|---|---|---|---|
| NPS | ID at End (1), (3), (4) | OD at Bevel (1), (2) | Centre-to- Centre O | Overall Length H | Centre -to- End Dimension A, B, C, M | Alignment of Ends U | Overall Length E |
| ½ to 2½ | 0.003 | 0.006 -0.003 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 3 to 3 ½ | 0.006 | 0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 4 | 0.006 | 0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 5 to 8 | 0.006 | 0.009 -0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.025 |
| 10 to 18 | 0.012 | 0.016 -0.012 | 0.038 | 0.009 | 0.009 | 0.006 | 0.025 |
| 20 to 24 | 0.019 | 0.025 -0.019 | 0.038 | 0.009 | 0.009 | 0.006 | 0.025 |
| 26 to 30 | 0.019 | 0.025 -0.019 | … | 0.019 | 0.012 | … | 0.038 |
| 32 to 48 | 0.019 | 0.025 -0.019 | … | 0.019 | 0.019 | … |
Inconel 617 pipe fittings offer several key advantages, making them ideal for high-temperature and corrosive environments. Their exceptional resistance to oxidation, carburization, and scaling ensures long-term durability, even in extreme conditions. The alloy maintains high strength and excellent creep resistance at temperatures up to 2000°F (1093°C), making it suitable for demanding industrial applications. Inconel 617 also provides superior resistance to high-temperature corrosion, ensuring reliability in the aerospace, power generation, and chemical industries. Additionally, it exhibits excellent weldability and fabricability, offering ease of installation and maintenance in complex systems.
|
Nominal
Pipe
Size |
45° Elbow |
90° Elbow |
OD |
180° Returns |
||||
|
(inch.) |
LR |
SR |
LR |
LR |
||||
|
Radius
(inch.) |
Center to Face
(inch.) |
Center to Face
(inch.0) |
Center to Face
(inch.0) |
(inch) |
(millimeter) |
Back to face
(inch.) |
Center to Center
(inch.) |
|
|
1/2 |
5/8 |
– |
1 1/2 |
0.0840 |
21.03 |
1 7/8 |
2 |
|
|
3/4 |
7/16 |
– |
1 1/8 |
1.0050 |
26.07 |
1 11/16 |
2 1/4 |
|
|
1 |
7/8 |
1 |
1 1/2 |
1.0315 |
33.04 |
2 3/16 |
3 |
|
|
1 1/4 |
1 |
1 1/4 |
1 7/8 |
1.0660 |
42.02 |
2 3/4 |
3 3/4 |
|
|
1 1/2 |
3 |
1 1/8 |
1 1/2 |
2 1/4 |
1.0900 |
48.03 |
3 1/4 |
4 1/2 |
|
2 |
4 |
1 3/8 |
2 |
3 |
2.0375 |
60.03 |
4 3/16 |
6 |
|
2 1/2 |
5 |
1 3/4 |
2 1/2 |
3 3/4 |
2.0875 |
73.00 |
5 3/16 |
7 1/2 |
|
3 |
6 |
2 |
3 |
4 1/2 |
3.0500 |
88.09 |
6 1/4 |
9 |
|
3 1/2 |
7 |
2 1/4 |
3 1/2 |
5 1/4 |
4.0000 |
101.06 |
7 1/4 |
10 1/2 |
|
4 |
8 |
2 1/2 |
4 |
6 |
4.0500 |
114.03 |
8 1/4 |
12 |
|
5 |
10 |
3 1/8 |
5 |
7 1/2 |
5.0563 |
141.03 |
10 5/16 |
15 |
|
6 |
12 |
3 3/4 |
6 |
9 |
6.0625 |
168.03 |
12 5/16 |
18 |
|
8 |
12 |
5 |
8 |
12 |
8.0625 |
219.01 |
16 5/16 |
24 |
|
10 |
15 |
6 1/4 |
10 |
15 |
10.0750 |
273.01 |
20 3/8 |
30 |
|
12 |
18 |
7 1/2 |
12 |
18 |
12.0750 |
323.09 |
24 3/8 |
36 |
Yes, custom sizes for Inconel 617 Pipe Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.
Inconel 617 pipe fittings are widely used in industries requiring high-temperature and corrosion-resistant materials. They are commonly employed in aerospace applications, including turbine engines, and in power generation systems such as gas turbines and reactors. The alloy’s resistance to oxidation and carburization makes it ideal for chemical processing, petrochemical, and refining industries, where high-temperature corrosion is a concern. Inconel 617 fittings are also used in industrial furnaces, heat exchangers, and other high-stress environments, ensuring durability and performance in challenging operational conditions.
Stainless Steel 201 Pipe Fittings are composed of 16-18% chromium, 3.5-5.5% nickel, 5.5-7.5% manganese, and 0.15% maximum carbon, offering excellent durability and corrosion resistance. These fittings exhibit impressive mechanical properties, including a tensile strength of 515 MPa and a yield strength of 275 MPa. With an elongation of 40% and a Brinell hardness of 217 HBW, they ensure reliable performance in demanding environments. The combination of lightweight structure and superior strength makes Stainless Steel 201 Pipe Fittings ideal for various applications, such as construction, chemical processing, and food industries.
