Inconel 601 Pipe Fittings Manufacturer and Supplier in Houston, USA

Harry Fittings, based in Houston, USA, is a reliable pipe fittings manufacturer and supplier of top-quality pipe fittings for a wide variety of industrial uses. With its reputation for accuracy engineering, strength, and innovation, the company provides products that surpass international standards. Among its top-grade products, Inconel 601 Pipe Fittings are noteworthy for their superior heat, oxidation, and corrosion resistance to suit challenging and high-temperature conditions. Supported by a customer-focused strategy, Harry Fittings provides affordable, reliable, and efficient piping solutions for critical sectors like chemical processing, power generation, and aerospace.

Inconel 601 Pipe Fittings In USA, 601 Inconel Alloy Butt weld Pipe Fittings United kingdom, Inconel® 601 Pipe Fittings Suppliers Houston, Alloy 601 Buttweld Fittings Los Angeles, ASTM B366 Inconel 601 Pipe Elbow Houston, 601 Inconel Alloy Buttweld Tee Dealer Texas, Inconel Grade 601 Butt weld Pipe Fittings Stockists California, Distributors of Inconel® Alloy 601 ASME SB366 Buttweld Reducer in Houston, USA.

Inconel 601 Pipe Fittings Specification

Specifications ASTM B366 / ASME SB366

Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, MSS SP-79

Size 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)

Type Seamless / Welded / Fabricated

Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Thickness Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Grade 601 UNS (N06601), DIN (2.4851)

Inconel 601 Pipe Fittings contain a major portion of Nickel (58–63%), Chromium (21–25%), and Iron with minor additions of Aluminum (1–1.7%), Manganese (≤1%), Silicon (≤0.5%), and Carbon (≤0.1%). Such an ideal alloy mix offers superior resistance to oxidation and corrosion even at high temperatures. In terms of mechanical properties, Inconel 601 has minimum tensile strength of 550 MPa, minimum yield strength of 205 MPa, and minimum elongation of 30%, which retains its shape up to 1200°C. These properties render it as a best-suited material for use in high-stress thermal and chemically corrosive conditions.

Inconel 601 Pipe Fittings Chemical Composition

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr
Inconel 601	0.10 max	1.0 max	0.5 max	0.015 max	1.0 max	Balance	58.0 – 63.0	21.0 – 25.0

Inconel 601 Pipe Fittings Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.1 g/cm3	1411 °C (2571 °F)	Psi – 80,000 , MPa – 550	Psi – 30,000 , MPa – 205	30 %

601 Inconel Welded Pipe Fittings Suppliers In USA, UNS N06601 Nickel Alloy Butt weld Seamless Pipe Fitting United kingdom, 601 Inconel® 45°/90°/180° Butt weld Elbow Houston, Nickelvac® 601 Pipe Fittings Los Angeles, Alloy 601 Equal Tee Wholesaler Houston, ASME B16.28 601 Inconel Alloy Butt weld Reducing Tee Texas, 601 Inconel® Unequal Cross Exporters California, 601 Alloy ANSI B16.9 Short & Long Radius Elbow In Houston, USA.

Largest Inconel 601 Pipe Fittings Supplier in Houston, USA

Harry Fittings is a leading supplier of Inconel 601 Pipe Fittings in Houston, USA. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Inconel 601 Pipe Fittings Equivalent Grade

STANDARD	UNS	WNR.	AFNOR	EN	JIS	BS	GOST	OR
Alloy 601	N06601	2.4851	NiCr23Fe	NiCr15Fe	NCF 601	NA 49	XH60BT	ЭИ868

Why Choose Inconel 601 Pipe Fittings from Harry Fittings?

Inconel 601 Pipe Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Werkstoff No 2.4851 Inconel® Butt weld Eccentric Reducer Traders In USA, 601 Nickel Alloy Concentric Reducer United kingdom, Ferrochronin® 601 Pipe Fittings Houston, Inconel Pipe Fittings Los Angeles, Inconel 601 Seamless Pipe Fittings Houston, MSS SP-79 Inconel Alloy 601 End Pipe Cap Suppliers In Texas, Inconel 601 MSS-SP-43 Buttweld Swage Nipple California, Inconel® Alloy JIS NCF 601 Stub Ends Exporters In Houston, USA.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Inconel 601 Pipe Fittings offer numerous advantages, making them ideal for demanding applications. They excel in high-temperature resistance, maintaining strength and stability up to 1200°C. Their exceptional oxidation and corrosion resistance ensures durability in harsh environments, including chemical processing and thermal cycling. The addition of aluminum enhances their protective oxide layer, resisting spalling and scaling. These fittings also provide excellent mechanical strength and creep resistance under stress, along with good weldability. Their versatility and reliability make them indispensable in power generation, aerospace, and heat treatment industries.

Inconel 601 Pipe Fittings Size Chart

Product range and theoretical weights (kg)
DN	Schedule 10S			Schedule 40S			Schedule 80S
DN	90° Elbow	45° Elbow	Equal tee	90° Elbow	45° Elbow	Equal tee	90° Elbow	45° Elbow	Equal tee
8	0.02	0.01	0.03	0.03	0.02	0.06	0.04	0.03	0.07
10	0.03	0.02	0.05	0.03	0.02	0.03	0.06	0.04	0.09
15	0.06	0.03	0.09	0.08	0.04	0.10	0.10	0.05	0.14
20	0.07	0.03	0.13	0.08	0.04	0.17	0.11	0.05	0.20
25	0.14	0.08	0.28	0.15	0.11	0.29	0.22	0.14	0.38
32	0.23	0.11	0.49	0.26	0.17	0.59	0.40	0.23	0.68
40	0.30	0.17	0.68	0.40	0.23	0.86	0.51	0.29	1.02
50	0.50	0.25	0.85	0.70	0.4	1.28	0.91	0.59	1.59
65	0.85	0.48	1.41	1.40	0.77	2.19	1.81	0.99	3.13
80	1.25	0.63	1.77	2.20	1.08	3.31	2.97	1.50	4.45
90	1.70	0.75	2.67	2.83	1.42	4.08	4.00	2.00	5.44
100	2.10	1.08	3.46	4.47	2.09	5.27	6.18	2.81	7.71
150	5.45	2.72	8.07	10.89	5.44	10.99	16.32	8.16	13.61
200	10.20	5.33	15.65	21.54	10.77	20.91	33.11	16.56	28.12
250	18.15	9.75	26.46	38.56	19.27	35.38	51.71	25.86	49.90
300	25.80	13.62	39.46	59.42	29.71	62.14	79.38	39.69	83.91

Types of Inconel 601 Pipe Fittings

Are Custom Sizes Available for Inconel 601 Pipe Fittings?

Yes, custom sizes for Inconel 601 Pipe Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.

Werkstoff No 2.4851 Inconel® Butt weld Eccentric Reducer Traders In USA, 601 Nickel Alloy Concentric Reducer United kingdom, Ferrochronin® 601 Pipe Fittings Houston, Inconel Pipe Fittings Los Angeles, Inconel 601 Seamless Pipe Fittings Houston, MSS SP-79 Inconel Alloy 601 End Pipe Cap Suppliers In Texas, Inconel 601 MSS-SP-43 Buttweld Swage Nipple California, Inconel® Alloy JIS NCF 601 Stub Ends Exporters In Houston, USA.

Application Industry of Inconel 601 Pipe Fittings

Inconel 601 Pipe Fittings find extensive applications in instances requiring resistance to oxidation, heat, and corrosion. They are used effectively in the handling of corrosive materials and high temperatures in chemical processing units. They are heavily utilized in thermal process equipment, including furnaces, kilns, and heat-treating equipment, owing to its resistance to spalling and thermal stability. In power generation, the fittings are dependable in boilers, superheaters, and gas turbines. They are also used in aerospace, particularly in exhaust systems and pollution control devices such as incinerators, where they provide a consistent performance level in high-stress, high-temperature applications.
