Hastelloy Forged Fittings

Harry Fittings, a top producer and supplier of premium Hastelloy Forged Fittings with its headquarters located in Houston, USA, offers exceptional corrosion-resistant solutions for harsh and hot conditions. Harry Fittings provides a wide variety of forged elbows, tees, couplings, unions, and plugs to the chemical processing, marine, and pharmaceutical industries. High performance and dependability are guaranteed by the manufacturing of these fittings in accordance with ASTM B564 and other international standards. Customers looking for sturdy alloy fittings that can withstand the most extreme chemical and environmental conditions can trust Harry Fittings because of its reputation for accuracy, dependability, and prompt delivery.

Werkstoff No. 2.4617 Hastelloy High Pressure Forged Fittings USA, Manufacturer Of ASTM B564 C276 Hastelloy Bushing United kingdom, Hastelloy ASTM B564 B2 Cross Houston, Hastelloy C22 Equal Tee Los Angeles, X Hastelloy Full Couplings Houston, BS 3799 Union Texas, Alloy C4 Forged 90 Deg Screwed Threaded Elbow in California.

Hastelloy Forged Fittings Specification

Specifications	ASTM B564 & ASME SB564
Standard	ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size	1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Grades	Hastelloy C276, C22, C4, C2000, B2, B3, X Forged Fittings
Type	Socketweld Fittings, Screwed-Threaded Fittings
Class	2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS

Typically, Hastelloy Forged Fittings are composed of nickel-based alloys like Hastelloy C22, C276, or C2000, which contain trace amounts of iron, cobalt, and tungsten along with high concentrations of nickel (≈56–59%), molybdenum (13–17%), and chromium (15–22%). These fittings have an elongation of 45–60%, a yield strength of about 283 MPa, and a tensile strength of 690–760 MPa. Hastelloy is well-known for its remarkable resistance to pitting, crevice corrosion, and stress-corrosion cracking. It also retains its strength and toughness in extremely corrosive and hot conditions, which makes it perfect for demanding process conditions and vital piping systems.

Hastelloy Forged Fittings Chemical Composition

Grade	C	Mn	Si	S	Co	Ni	Cr	Fe	Mo	P
C276	0.010 max	1.00 max	0.08 max	0.03 max	2.50 max	50.99 min*	14.50 – 16.50	4.00 – 7.00	15.00 – 17.00	0.04 max
C22	0.010 max	0.50 max	0.08 max	0.02 max	2.50 max	50.015 min*	20.00 – 22.50	2.00 – 6.00	12.50 – 14.50	0.02 max
B2	0.02 max	1.0 max	0.1 max	0.03 max	1.0 max	Bal	1.0 max	2.0 max	26 – 30	0.04 max

Hastelloy Forged Fittings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Hastelloy C276	8.89 g/cm3	1370 °C (2500 °F)	Psi – 1,15,000 , MPa – 790	Psi – 52,000 , MPa – 355	40 %
Hastelloy C22	8.69 g/cm3	1399 °C (2550 °F)	Psi – 1,00,000 , MPa – 690	Psi – 45000 , MPa – 310	45 %
Hastelloy B2	9.2 g/cm3	1370 °C (2500 ºF )	Psi – 1,10,000 , MPa – 760	Psi – 51000 , MPa – 350	40 %

Hastelloy Forged Fittings Standards / Types And Pressure Class

ASME 16.11, MSS SP-79, 83, 95, 97 Forged Pipe Fittings USA, Hastelloy UNS N10276 Forged Pipe Fittings United kingdom, Stockist of Alloy C22 Forged Elbow Houston, Hastelloy C276 Forged Fittings Los Angeles, Hastelloy UNS N10665 Forged Fittings Houston, Global Supplier of Hastelloy B2 Socket weld Fittings Texas, C2000 Hastelloy Threaded Fittings Dealer in California.

ASME SB564 Hastelloy Forged Fittings Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS	JIS	GOST	EN	OR
Hastelloy C276	2.4819	N10276	NW 0276	ХН65МВУ	NiMo16Cr15W	ЭП760
Hastelloy C22	2.4602	N06022	NW 6022	–	NiCr21Mo14W	–
Hastelloy B2	2.4617	N10665	–	–	–	–

Harry Fittings is a leading supplier of Hastelloy Forged Fittings in Houston, USA. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Why Choose Hastelloy Forged Fittings from Harry Fittings?

Hastelloy Forged Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Best Price of B2 Hastelloy 3000 LB Forged Screwed Fittings Exporter In USA, DIN 2.4819 Hastelloy Alloy Street Elbow United kingdom, Hastelloy Alloy DIN 2.4602 Forged Steel Fittings Houston, Stockholder Of Hastelloy UNS N06455 Threaded Plug Los Angeles, Hastelloy UNS N06200 Socket Weld Cap Houston, ASME SB564M Hastelloy C22 Class 6000 Fittings Wholesaler Texas, C276 Hastelloy Alloy Pipe Nipple Traders in California.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Types of Hastelloy Forged Fittings

Are Custom Sizes Available for Hastelloy Forged Fittings?

Yes, custom sizes for Hastelloy Forged Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.

ASME 16.11, MSS SP-79, 83, 95, 97 Forged Pipe Fittings USA, Hastelloy UNS N10276 Forged Pipe Fittings United kingdom, Stockist of Alloy C22 Forged Elbow Houston, Hastelloy C276 Forged Fittings Los Angeles, Hastelloy UNS N06200 Socket Weld Cap Houston, ASME SB564M Hastelloy C22 Class 6000 Fittings Wholesaler Texas, C276 Hastelloy Alloy Pipe Nipple Traders in California.

Application Industry of Hastelloy Forged Fittings

Industries that need outstanding resistance to harsh chemicals, high temperatures, and mechanical stress frequently use Hastelloy Forged Fittings. Chemical processing, pharmaceutical manufacturing, bleaching systems for pulp and paper, marine engineering, and pollution control are examples of common applications. Reactors, scrubbers, heat exchangers, and pressure vessels can all benefit from these fittings because they are perfect for systems that are subjected to strong acids, chlorides, oxidisers, and reducing agents. For long-term operation in harsh chemical and thermal conditions, Hastelloy fittings are the material of choice because of their exceptional mechanical stability and resistance to corrosion.
