Based in Houston, USA, Harry Fittings is a reputable producer and supplier of carbon steel P265GH pipe fittings. Harry Fittings, a company renowned for providing precisely engineered piping solutions, provides premium P265GH pipe fittings that satisfy global pressure equipment standards. These fittings are frequently utilised in applications that call for exceptional durability, strength, and resistance to temperature. Serving a wide range of industries, including oil and gas, power generation, and chemical processing, Harry Fittings is dedicated to quality assurance, advanced manufacturing capabilities, and on-time delivery. For dependable and effective piping components, clients depend on the company’s technical know-how and customer-focused methodology.
| P265GH Carbon Steel Pipe Fittings size | P265GH Seamless Butt Weld Fittings : 1/2″ – 10″ P265GH Welded Butt Weld Fittings : 1/2″ – 48″ |
|---|---|
| CS P265GH Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1800, BS10 |
| P265GH Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| P265GH Buttweld Pipe FittingsType | DN15-DN1200 |
| EN 10253-1 / EN 10253-2 P265GH Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM A234 Gr P265GH Pipe Fitting |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM A234 P265GH Buttweld Fitting |
| EN 10253-1 / EN 10253-2 P265GH Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| P265GH Carbon Steel Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| EN 10253-1 P265GH Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | CS 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
| We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Carbon (up to 0.20%), manganese (0.80–1.60%), phosphorus (≤0.025%), sulphur (≤0.015%), and silicon (≤0.40%) make up the majority of Carbon Steel P265GH Pipe Fittings. These fittings are renowned for their exceptional strength under pressure and weldability. A minimum tensile strength of 410–530 MPa and a minimum yield strength of 265 MPa are among the mechanical characteristics. P265GH is perfect for use in high-temperature settings because of its high ductility and strong resistance to thermal stress. It is appropriate for boiler and pressure vessel applications due to its steady performance at high pressures.
| Element | % by mass | Element | % by mass |
| Carbon (C) | ≤0.20 | Silicon (Si) | ≤0.40 |
| Manganese (Mn) | 0.80 to 1.40 | Phosphorous (P) (maximum) | 0.025 |
| Sulphur (S) (maximum) | 0.015 | Aluminium (Al) | <=0.020 |
| Nitrogen (N) | <=0.012 | Chromium (Cr) | <=0.30 |
| Copper (Cu) | <=0.30 | Molybdenum (Mo) | <=0.08 |
| Niobium (Nb) | <=0.020 | Nickel (Ni) | <=0.30 |
| Titanium (Ti) (maximum) | 0.03 | Vanadium (Vi) | <=0.02 |
| Nominal thickness (millimeter): | to 100 | 100 – 150 | 150 – 250 |
| Rm – Tensile strength (MPa) (+N) | 410-530 | 400-530 | 390-530 |
Harry Fittings is a leading supplier of Carbon Steel P265GH Pipe Fittings in Houston, USA. We offer an extensive range of Carbon Steel P265GH Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Carbon Steel P265GH Pipe Fittings from Harry Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Yes, custom sizes for Carbon Steel P265GH Pipe Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us
| EU EN | USA – | Germany DIN,WNr | Japan JIS | France AFNOR | England BS | Italy UNI | Spain UNE | Sweden SS | Poland PN | Czechia CSN | Austria ONORM | Russia GOST | Inter ISO | ||||||||||||||||||||||||||||||
| P265GH Flange |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
| inch | mm | inch | Length (inch) | Center to End (inch) | Center to End (inch) | Lap Diameter (inch) | Long Length (inch) | Short Length (inch) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Industries that work in high-pressure and high-temperature environments frequently use carbon steel P265GH pipe fittings. They are frequently used in heat exchangers, pressure vessels, and steam boilers in the petrochemical, oil and gas, and power generation industries. These fittings are necessary for safe pipeline connections in systems that move gases, steam, or hot fluids. They are also utilised in refineries, chemical processing facilities, and HVAC systems because of their exceptional strength, formability, and resistance to thermal fatigue. Because P265GH fittings meet EN standards, they are particularly preferred in European and international pressure equipment.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
