Harry Fittings, a top-notch manufacturer and supplier located in Houston, USA, proudly offers a premium selection of ASTM A860 WPHY 70 pipe fittings. Renowned for their outstanding strength and durability, these fittings are specifically engineered to handle the tough demands of high-pressure applications. With a strong emphasis on quality and precision, Harry Fittings delivers solutions that comply with international standards, ensuring reliability for critical infrastructure projects. Catering to industries like oil and gas, petrochemical, and power generation, Harry Fittings is dedicated to providing high-performance products along with exceptional customer service.
| size | Seamless Fittings: 1/2″ – 10″ Welded Fittings: 1/2″ – 48″ |
|---|---|
| Dimensions | BS4504, ASME B16.28, ASME/ANSI B16.9, MSS-SP-43, BS4504, BS1560, BS10 |
| Thickness | SCH20, SCH 100, SCH30, STD SCH40, SCH10, SCH60, XS, SCH 80, SCH 120, SCH 140, SCH 160, XXS |
| Type | DN15-DN1200 |
| Connection | Welding |
| Elbows Manufacturer | Angle : 1.0D, 22.5 deg, 90 deg, 30deg, 45 deg, 180 deg, 5D, 6D, 1.5D, 2.0D, 2.5D, 3D, 4D, 7D-40D . Standard: ASME B16.9, ASME B16.28, BS, GB, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, ISO |
| Manufacturing process | Press, Push, Forge, Cast, etc. |
| Surface treatment | Sand Rolling, Sand blasting, Sand Blasting |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Origin & Mills | USA, Korean, Japanese, Indian, European, Ukraine, Russian |
| Key markets and industries |
|
| Specialized Manufacturer of | Pipe Bend, Crosses, 45º Elbows, Reducers, Tees, 90º Elbows, Pipe Cap, Stub End |
ASTM A860 WPHY 70 pipe fittings are made from high-strength low-alloy steel. The material typically includes elements such as carbon, manganese, and silicon, which contribute to their enhanced strength and toughness. These fittings boast impressive mechanical properties, featuring a minimum yield strength of 485 MPa and a tensile strength ranging from 570 to 690 MPa. Their remarkable impact resistance and ductility make them ideal for extreme temperature and pressure conditions, ensuring reliable performance in demanding applications.
|
C |
Mn |
P |
S |
Si |
Ni |
Cr |
Mo |
Cu |
Ti |
V |
Cb |
Al |
|
|
A860 |
0.20 |
1.00-1.45 |
0.03 |
0.01 |
0.15-0.40 |
0.50 |
0.30 |
0.25 |
0.35 |
0.05 |
0.10 |
0.04 |
0.06 |
| Element | Tensile Strength(Min PSI) | Yield Strength (Min PSI) | Elongation(%, in 2in.) |
| WPHY 70 | 82000 PSI | 70000 PSI | 20 % |
Harry Fittings is a leading supplier of ASTM A860 WPHY 70 Pipe Fittings in Houston, USA. We offer an extensive range of ASTM A860 WPHY 70 Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose ASTM A860 WPHY 70 Pipe Fittings from Harry Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
ASTM A860 WPHY 70 Pipe Fittings offer several key advantages, including exceptional strength and durability, with a tensile strength of 760 MPa and yield strength of 520 MPa, making them ideal for high-pressure applications. These fittings are highly resistant to impact, corrosion, and wear, ensuring long-lasting performance in harsh environments. Their excellent toughness makes them suitable for low-temperature and offshore applications. Designed for secure, leak-proof connections, ASTM A860 WPHY 70 fittings reduce maintenance and downtime, providing a reliable and cost-effective solution for critical pipeline systems in industries like oil, gas, and petrochemicals.
Yes, custom sizes for ASTM A860 WPHY 70 Pipe Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
| inch | mm | inch | Length (inch) | Center to End (inch) | Center to End (inch) | Lap Diameter (inch) | Long Length (inch) | Short Length (inch) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
ASTM A860 WPHY 70 pipe fittings are extensively used in industries that require robust high-pressure handling capabilities. They play a crucial role in oil and gas pipelines, transporting crude oil and natural gas over long distances, as well as in petrochemical plants where they manage corrosive and high-temperature substances. Additionally, these fittings are vital for power generation systems, water treatment facilities, and structural applications in various industrial projects. Their ability to endure high pressures, harsh environments, and mechanical stress makes them perfect for critical infrastructure and heavy-duty operations.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
