Harry Fittings is a leading American manufacturer and supplier of Alloy Steel WP5 Buttweld Fittings, based in Houston, USA. With its excellence in precision engineering and dependable performance, we provide a complete range of fittings—ranging from elbows and tees through reducers to caps—engineered to withstand the stringent demands of industries across the globe. Our WP5 fittings are engineered to withstand high temperature and high pressure conditions, making them a perfect fit for power generation, petrochemical, and oil & gas industries. Products are aligned with international quality standards, guaranteeing durable performance and leak-proof dependability. Customer satisfaction and operational excellence are our priorities at Harry Fittings.
| Specifications | : | ASTM A234 / ASME SA234 |
| Size | : | 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated) |
| Standards | : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | : | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
| Type | : | Seamless / Welded / Fabricated |
Alloy Steel WP5 Buttweld Fittings consist of chromium (5%), molybdenum (0.5%), and controlled quantities of carbon, manganese, silicon, phosphorus, and sulfur. This particular combination of alloys provides higher mechanical strength, resistance to oxidation, and thermal stability. The fittings have excellent tensile strength, yield strength, and elongation, which makes them preferable for high-stress applications. Famed for their dimensional precision, creep resistance, and hardness, WP5 fittings offer long-term reliability under extreme conditions, like those in boilers, pressure vessels, and heat exchangers, which are found in typical process industries.
| Grade | C | Mn | Si | S | P | Cr | Mo |
| A234 WP5 | ≤0.15 | ≤0.6 | ≤0.5 | ≤0.04 | ≤0.03 | 4-6 | 0.44-0.65 |
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| A234 WP5 | 415 – 585 | ≥205 | ≥20 |
Harry Fittings one of the largest suppliers of Alloy Steel WP5 Buttweld Fittings in Houston, USA. We specialize in providing a wide range of high-quality, durable fittings for various industrial applications. Our inventory includes elbows, tees, reducers, couplings, and other essential fittings designed to offer exceptional corrosion resistance and strength. Alloy Steel WP5 is known for its cost-effectiveness and excellent mechanical properties, making it ideal for industries such as construction, chemical processing, and food processing. With a commitment to customer satisfaction, timely delivery, and competitive pricing, we are the trusted choice for Alloy Steel WP5 Buttweld Fittings in the USA.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Alloy Steel WP5 Buttweld Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| O.D. or I.D. Diameter | Equivalent Decimal | Nominal Diameter | Typical Threads In Inch |
| 5/16 | 0.313 | 1/16 | 27 |
| 13/32 | 0.405 | 1/8 | 27 |
| 35/64 | 0.540 | 1/4 | 18 |
| 43/64 | 0.675 | 3/8 | 18 |
| 27/32 | 0.840 | 1/2 | 14 |
| 1-3/64 | 1.050 | 3/4 | 14 |
| 1-5/16 | 1.315 | 1 | 11-1/2 |
| 1-21/32 | 1.660 | 1-1/4 | 11-1/2 |
| 1-29/32 | 1.900 | 1-1/2 | 11-1/2 |
| 2-3/8 | 2.375 | 2 | 11-1/2 |
| 2-7/8 | 2.875 | 2-1/2 | 8 |
| 3-1/2 | 3.500 | 3 | 8 |
| 4 | 4.000 | 3-1/2 | 8 |
| 4-1/2 | 4.500 | 4 | 8 |
Alloy Steel WP5 Buttweld Fittings offer exceptional durability, making them ideal for high-pressure and high-temperature environments. Their superior resistance to corrosion, oxidation, and wear ensures longevity, even in harsh industrial conditions. The fittings provide excellent tensile and yield strength, ensuring structural integrity in critical applications. Their seamless design minimizes the risk of leaks and ensures efficient flow of fluids or gases. Easy to weld and install, these fittings reduce downtime during maintenance. Cost-effective and reliable, Alloy Steel WP5 Buttweld Fittings are a preferred choice for demanding industries like oil and gas, power generation, and petrochemicals.
| ASTM A234 WP5 Pipe Fittings (Grade WP5 To WP91) Tolerance | 90 Deg And 45 Deg Elbows And Pipe Tee | Reducer (Concentric/ Eccentric) & Lap Joint Stub End (Long / Short) | Pipe End Caps | |||
| Normal Pipe Size (NPS) Of ASME B16.9 | O. (Outside) D. (Daimeter) at Bevel | I. (Inside) D.(Daimeter) at End | Wall Thickness Of T | Center-to-End Dimension A ,C ,B | Over-all Length Of H | Over-all Length Of F |
| 1/2 to 2-1/2 | +0.06 | Not less than 87.5% of nominal thickness | +/- 0.06 | +/- 0.06 | +/- 0.12 | |
| -0.03 | ||||||
| 3 to 3-1/2 | +/- 0.06 | +/- 0.06 | +/- 0.06 | +/- 0.06 | +/- 0.12 | |
| 4 | +/- 0.06 | +/- 0.06 | +/- 0.06 | +/- 0.06 | +/- 0.12 | |
| 5 to 8 | +/- 0.06 | +/- 0.06 | +/- 0.06 | +/- 0.06 | +/- 0.25 | |
| 10 to 18 | +0.16 | +/- 0.12 | +/- 0.09 | +/- 0.09 | +/- 0.25 | |
| -0.12 | ||||||
| 20 to 24 | +0.25 | +/- 0.19 | +/- 0.09 | +/- 0.09 | +/- 0.25 | |
| -0.19 | ||||||
| 26 to 30 | +0.25 | +/- 0.19 | +/- 0.12 | +/- 0.19 | +/- 0.38 | |
| -0.19 | ||||||
| 32 to 48 | +0.25 | +/- 0.19 | +/- 0.19 | +/- 0.19 | +/- 0.38 | |
| -0.19 | ||||||
Yes, custom sizes are available for Alloy Steel WP5 Buttweld Fittings to meet specific requirements. We offer tailored solutions to ensure precise fit and performance for various applications. For more information, please contact us at sales@harryfittings.us.
| STANDARD | 348H Pipe Fittings |
| EN | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| JIS | SUS 316L |
| BS | 316S11 / 316S13 |
| UNS | S34809 |
| WERKSTOFF NO. | 1.4546 |
| AFNOR | Z7CND17‐11‐02 |
| GOST | 03Ch17N14M3 / 03Ch17N14M2 |
Alloy Steel WP5 Buttweld Fittings are extensively used in high–strength and thermally resistant industries. In power generation applications, they are a component of steam lines, boilers, and superheaters because of their strength in handling high temperatures and pressures. Their use in pipeline systems, refinery process, and offshore platforms is dependent on the oil and gas industry. WP5 fittings provide corrosion-resistant, leak-free fluid flow in petrochemical and chemical processing plants under harsh conditions. Their durability, strength, and scaling resistance make them suitable for industrial use requiring long service life and low maintenance.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
