Harry Fittings, a top-notch manufacturer and supplier located in Houston, USA, is all about high-quality Incoloy Buttweld Fittings. Known for their precision engineering and commitment to global standards, this company caters to a diverse range of industries with fittings that are celebrated for their durability, corrosion resistance, and dependable performance even in extreme conditions. With a strong focus on customer satisfaction, Harry Fittings provides tailored solutions backed by technical know-how and quick service. Their Incoloy Buttweld Fittings are commonly used in critical applications, ensuring safe and efficient handling of fluids and gases in high-temperature and corrosive environments.
| Specifications | : | ASTM B366 / ASME SB366 |
| Size | : | Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″ |
| Standards | : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | : | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | : | Seamless / Welded / Fabricated |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
| 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
Incoloy Buttweld Fittings are primarily made up of nickel, iron, and chromium, with some grades including molybdenum, copper, and titanium. These alloys are fantastic at resisting oxidation and carburization at high temperatures. On the mechanical side, Incoloy fittings boast high tensile strength, good elongation, and remarkable creep resistance. They maintain stability and structural integrity even in harsh operating conditions, making them perfect for demanding environments. The blend of strong mechanical properties and chemical composition guarantees top-notch performance in aggressive industrial settings.
Harry Fittings is a leading supplier of Incoloy Buttweld Pipe Fittings in Houston, USA. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy Pipe Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy Buttweld Fittings offer numerous advantages, making them a preferred choice across industries. Their excellent corrosion resistance ensures durability in harsh environments, including high temperatures and chemical exposure. These fittings provide superior mechanical strength, reducing the risk of failure under pressure. The seamless construction enhances flow efficiency and eliminates weak points, ensuring long-term reliability. Incoloy’s resistance to oxidation and stress-corrosion cracking adds to its versatility, making it ideal for marine, chemical, and power industries. Easy to weld and install, these fittings also ensure leak-proof and robust connections.
Yes, custom sizes for Incoloy Pipe Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.
You’ll find Incoloy Buttweld Fittings used across various industries, including petrochemical, power generation, chemical processing, marine, and oil & gas. Their outstanding corrosion resistance and thermal stability make them ideal for heat exchangers, pressure vessels, reactors, and piping systems that deal with corrosive fluids or operate under extreme temperatures. These fittings are vital in applications where leak-proof connections and long-lasting durability are a must. Plus, their versatility in welding and fabrication processes boosts their usefulness in complex installations, ensuring reliable and efficient system performance across a range of high-demand sectors.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
