Harry Fittings is a well-respected manufacturer and supplier of top-quality Incoloy 800, 800H, and 800HT Forged Fittings, proudly based in Houston, USA. With a strong focus on quality, precision engineering, and customer satisfaction, the company provides a diverse selection of forged fittings that adhere to international standards. These high-performance fittings are celebrated for their outstanding resistance to oxidation, carburization, and high-temperature corrosion, making them perfect for demanding industrial settings. Supported by state-of-the-art manufacturing facilities and a talented workforce, Harry Fittings guarantees reliable and durable solutions for various industries throughout the United States and beyond.
Incoloy Alloy 800/800H/800HT Forged Fittings Specification
Specifications ASTM B366 / ASME SB366
Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, MSS SP-79
Size 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Type Seamless / Welded / Fabricated
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Thickness Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Grade 800 / 800H / 800HT UNS (N08800, N08810, and N08811), DIN (1.4876, 1.4958, and 1.4959)
| Grade | Ni | Fe | Cr | Cu | Ti | Al | C | Mn | S | Si |
| Incoloy 800 | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .15-.60 | .15-.60 | .1 max | 1.5 max | .015 max | 1.0 max |
| Incoloy 800H | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .15-.60 | .15-.60 | .05-.10 max | 1.5 max | .015 max | 1.0 max |
| Incoloy 800HT | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .25-.60 | .85-1.20 | .06-.10 max | 1.5 max | .015 max | 1.0 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | Psi – 30,000 , MPa – 205 | 30 – 35 % |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32T |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4959 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
Incoloy 800, 800H, and 800HT Forged Fittings are nickel-iron-chromium alloys that boast high levels of nickel (30–35%) and chromium (19–23%), delivering remarkable strength and oxidation resistance. The carbon content gradually increases from 800 to 800HT, which enhances their creep and rupture properties. These fittings showcase a tensile strength of about 500–600 MPa and a yield strength of roughly 200–275 MPa, along with impressive elongation and excellent thermal stability. Their mechanical integrity holds up well at elevated temperatures, making them suitable for high-stress and high-heat environments.
Harry Fittings is a leading supplier of Incoloy 800/ 800H/ 800HT Forged Fittings in Houston, USA. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy 800/ 800H/ 800HT Forged Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy 800/800H/800HT Forged Fittings offer numerous advantages, including exceptional resistance to high-temperature oxidation, carburization, and corrosion. They maintain structural stability under thermal cycling and prolonged exposure to elevated temperatures, ensuring reliability in demanding environments. These fittings exhibit excellent mechanical strength, creep, and stress rupture resistance, making them ideal for critical applications. Their versatility allows for use in various industries, such as petrochemical, chemical processing, and power generation. Additionally, their durability and low maintenance requirements reduce operational costs, ensuring long-term performance and efficiency in challenging conditions.
Yes, custom sizes for Incoloy 800/ 800H/ 800HT Forged Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us
Incoloy 800/800H/800HT Forged Fittings are commonly utilized in applications that demand exceptional high-temperature strength and corrosion resistance. Industries such as petrochemical, power generation, heat treatment, and oil & gas depend on these fittings for use in furnaces, heat exchangers, reformer tubing, and superheaters. They perform reliably in sulfur-rich, carburizing, and oxidizing conditions, ensuring a long service life and minimizing maintenance needs. Their ability to resist scaling and deformation under thermal stress makes them essential in critical processing operations where reliability and structural integrity are vital for maintaining operational safety and efficiency.
