Harry Fittings is a prominent US-based manufacturer and supplier of premium industrial pipe fittings, with its main office in Houston, USA. The company is acclaimed for precision-made engineering, dependable performance, and superior customer service. Its extensive range of fitting solutions for a variety of industrial purposes caters to the needs of various industries. Among its premium products, Nickel Alloy 201 Pipe Fittings stand out for superior corrosion resistance, thermal stability, and long-term durability. These fittings are particularly designed for chemical processing, maritime, and aerospace applications. Crafted to industry standards, Harry Fittings provides strong, efficient, and tailored solutions for demanding conditions.
| Specifications | ASTM B366 / ASME SB366, ASTM B366 UNS N02201, ASME SB366 UNS N02201 | |
|---|---|---|
| Ni Alloy 201 Pipe Fittings size | Alloy 201 Seamless Butt Weld Fittings: 1/2″ – 10″ Alloy 201 Welded Butt Weld Fittings: 1/2″ – 48″ | |
| UNS N02201 Pipe Fittings Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504 , BS4504, BS1560, BS10 | |
| Nickel Alloy 201 Fittings Available Thickness | Schedule 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 | |
| ASTM B366 UNS N02201 Buttweld fitting Main Types | Seamless / Welded / Fabricated | |
| ASME SB 564 201 Fittings Thread | NPT , BSPT, BSPP | |
| Nickel Alloy Ni201 Fittings Type | DN15-DN1200 | |
| End | Threaded, Welding, JIC | |
| 2.4068 Nickel Hydraulic Tube Fittings Pressure Rating |
|
|
| Connection | Welding | |
| UNS 2201 Buttweld Fitting Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc | Application |
|
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | ||
Nickel Alloy 201 Pipe Fittings are produced using 99% pure nickel combined with traces of carbon, manganese, silicon, sulfur, and iron. This virtually pure composition guarantees excellent resistance to oxidation, corrosion, and high temperatures. The alloy provides good mechanical properties, such as tensile strength of 379–517 MPa (55–75 ksi), yield strength of 207–345 MPa (30–50 ksi), and elongation of 30–40%, to make it flexible and tough when stressed. Besides better weldability and ductility, these fittings are suitable for demanding high-temperature and corrosive service applications, which makes them a long-lasting solution for demanding operating conditions.
| Nickel 201 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| Balance | 0.15 max | – | 0.35 max | 0.35 max | 0.40 max | – | 0.01 max | 0.25 max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
Harry Fittings is a leading supplier of Nickel Alloy 201 Pipe Fittings in Houston, USA. We offer an extensive range of Nickel Alloy 201 Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Nickel 201 | N02201 | 2.4068 | – | LC-Ni 99 | NW 2201 | NA 12 | НП-2 |
Nickel Alloy 201 Pipe Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Nickel Alloy 201 pipe fittings offer excellent corrosion resistance, particularly in acidic environments, making them ideal for chemical processing, petrochemical, and marine applications. Their high electrical and thermal conductivity enhances performance in heat exchangers and electrical components. Nickel Alloy 201 also provides good weldability, fabrication ease, and stress-corrosion cracking resistance. It maintains mechanical strength at elevated temperatures, ensuring durability in high-heat environments. Additionally, its non-magnetic properties make it suitable for specialized applications where magnetism could be an issue, offering versatility and reliability in harsh conditions.
Yes, custom sizes for Nickel Alloy 201 Pipe Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.
Nickel Alloy 201 Pipe Fittings have broad usage in those industries necessitating high corrosion resistance and thermal endurance. In chemical processing, they are indispensable in the treatment of acidic and caustic solutions in reactors, piping, and tanks. In the marine industry, their ability to resist saltwater corrosion makes them a long-lasting component in shipbuilding and offshore structures. These fittings are also used in petrochemical applications, heat exchangers, and cryogenic plants, where mechanical strength and resistance to oxidation are important. They are also utilized by aerospace and electrical companies in high-temperature-exposed and corrosive environments, owing to their non-magnetic characteristics, strength, and stability.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
