Harry Fittings, located in Houston, USA, is a reliable manufacturer and supplier of high-performance Duplex Steel S32205 Pipe Fittings. These fittings are crafted to provide outstanding strength and corrosion resistance, making them perfect for tough industrial settings. Duplex S32205 is a nitrogen-enhanced duplex stainless steel that merges the advantages of both austenitic and ferritic steel structures, offering remarkable mechanical strength and resistance to stress corrosion cracking. Harry Fittings produces a comprehensive range of pipe fittings—including elbows, tees, reducers, and caps—that meet ASME B16.9, ASTM A815, and international quality standards. These fittings are ideal for use in the oil & gas, marine, chemical, and power generation industries.
| Specifications Standard | ASTM A815 /ASME SA815 |
|---|---|
| Duplex 2205 Pipe Fittings Size Range | Welded Fittings: 1/2″ – 48″ Seamless Fittings: 1/2″ – 10″ |
| Connection | Welding |
| Type | DN15 to DN1200 |
| Origin & Mills | Indian, European, Korean, Japanese, Ukraine, USA, Russian |
| Radius of bending | R=3D, 1D, 8D, 10D, 5D, 2D, Custom MSS Sp-43, 6D |
| Duplex 2205 Pipe Fittings Manufacturing process | Forge, Press, Cast, Push etc. |
| Thickness | SCH10, SCH40, XS, SCH30, SCH 160, SCH 80, SCH 140, SCH60, SCH20, STD , SCH 120, SCH 100, XXS |
| Pressure Ratings | 2000#, 150#, 6000#, 3000#, 9000# |
| End Connections: | socket weld and Threaded |
| Duplex 2205 Pipe Fittings manufacturer | 90º Tee, Elbows, Pipe Cap, Stub End, 45º Elbows, Crosses, Pipe Bend, Reducers |
| Dimensions | ASME B16.28, BS4504, MSS-SP-43, ASME/ANSI B16.9, BS1560, BS4504, BS10 |
| Elbows | Angle : 2.0D, 1.5D, 5D, 3D, 1.0D, 6D, 4D, 2.5D, 7D-40D . Standard: JISB2312, MSS SP-75, 22.5 deg, JISB2313, 30deg, ASME B16.9, 180 deg, 45 deg, JISB2311 BS, DIN2605, 90 deg, GB ISO |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate Third Party Inspection Report, etc |
Duplex Steel S32205 Pipe Fittings from Harry Fittings are made up of about 22% chromium, 5–6.5% nickel, and 3–3.5% molybdenum, along with nitrogen and manganese. This unique composition gives them excellent resistance to pitting, crevice corrosion, and chloride stress corrosion cracking. With a high yield strength of around 450 MPa and tensile strength of about 620 MPa—almost double that of standard austenitic stainless steels—these fittings maintain their mechanical stability even in harsh conditions. They undergo rigorous testing for pressure integrity, corrosion resistance, and dimensional accuracy, ensuring they are reliable for critical applications.
| Grade | C | Mn | Si | N | P | Cr | Fe | Ni | S | Mo |
| S32205 Fittings | 0.030 maximum | 2.00 maximum | 1.00 maximum | 0.8 to 0.20 | 0.030 maximum | 21.0 to 23.0 | 63.54 minimum | 4.50 to 6.50 | 0.020 maximum | 2.50 to 3.50 |
| Grades | Density (lb/in 3) | Melting Point (°F) | Density (g/centimeter 3) | Melting Point (°C) |
| S32205 Fittings | 0.285 | 2588 to 2669 | 7.805 | 1420 to 1465 |
Harry Fittings is a leading supplier of Duplex Steel S32205 Pipe Fittings in Houston, USA. We offer an extensive range of Duplex Steel S32205 Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Standard | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Super Duplex 2205 | 1.4462 | S32205 | – | – | – | – | – |
Duplex Steel S32205 Pipe Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Duplex Steel S32205 Pipe Fittings offer numerous advantages, including exceptional corrosion resistance, especially in chloride-rich environments. Their high strength-to-weight ratio makes them ideal for demanding applications while reducing structural load. The alloy’s superior resistance to stress corrosion cracking (SCC) and pitting enhances durability in harsh conditions. Duplex Steel S32205 fittings also exhibit excellent weldability, ensuring reliable connections. With good formability and high toughness, they are well-suited for chemical, marine, and oil and gas industries, providing long-lasting performance and reducing maintenance needs.
| NOMINAL PIPE SIZE | ALL FITTINGS | ALL FITTINGS | 180 DEG RETURN BENDS | REDUCERS | ELBOWS AND TEES | 180 DEG RETURN BENDS | CAPS |
|---|---|---|---|---|---|---|---|
| NPS | ID at End (1), (3), (4) | OD at Bevel (1), (2) | Centre-to- Centre O | Overall Length H | Centre -to- End Dimension A, B, C, M | Alignment of Ends U | Overall Length E |
| ½ to 2½ | 0.003 | 0.006 -0.003 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 3 to 3 ½ | 0.006 | 0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 4 | 0.006 | 0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 5 to 8 | 0.006 | 0.009 -0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.025 |
| 10 to 18 | 0.012 | 0.016 -0.012 | 0.038 | 0.009 | 0.009 | 0.006 | 0.025 |
| 20 to 24 | 0.019 | 0.025 -0.019 | 0.038 | 0.009 | 0.009 | 0.006 | 0.025 |
| 26 to 30 | 0.019 | 0.025 -0.019 | … | 0.019 | 0.012 | … | 0.038 |
| 32 to 48 | 0.019 | 0.025 -0.019 | … | 0.019 | 0.019 | … |
Yes, custom sizes for Duplex Steel S32205 Pipe Fittings are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.
Harry Fittings’ Duplex Steel S32205 Pipe Fittings are extensively utilized in offshore platforms, chemical processing facilities, desalination plants, pulp & paper mills, and power generation systems. Their dual-phase microstructure makes them particularly effective in environments rich in chlorides and high-pressure applications, such as seawater pipelines, heat exchangers, pressure vessels, and process piping systems. These fittings are also highly sought after in petrochemical refineries and marine industries, where durability and corrosion resistance are essential for long service life.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
