Reliable piping solutions for crucial industrial applications are provided by Harry Fittings, a respectable manufacturer and supplier of premium carbon steel forged fittings with headquarters in Houston, USA. Harry Fittings offers a large selection of forged elbows, tees, couplings, unions, and plugs that satisfy ASME and ASTM specifications, with an emphasis on accuracy, robustness, and performance. These fittings are widely trusted in the petrochemical, power, and oil and gas industries and are designed for use in high-pressure systems. As part of its dedication to quality, the business makes sure every fitting is put through a rigorous testing process to determine its strength, consistency, and long-term operational dependability.
| Forged Fittings Specifications | ASTM A105/ ASME SA105 |
|---|---|
| Carbon Steel Forged Fittings size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Carbon Steel Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Carbon Steel Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM A105 Carbon Steel Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Carbon Steel Forged Fittings Thread | NPT, BSPT, BSPP |
| Carbon Steel Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Carbon Forged Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
Carbon Steel Forged Fittings are usually made from grades such as ASTM A105 or A350 LF2, which are primarily made of silicon (0.10–0.35%), carbon (≤0.35%), manganese (0.60–1.05%), phosphorus (≤0.035%), and sulphur (≤0.040%). With a yield strength of at least 250 MPa and a tensile strength of about 485 MPa, these fittings provide exceptional strength and durability. To improve their mechanical qualities and ensure their durability in the face of high temperatures and pressures, they undergo heat treatment. They are perfect for harsh settings in industrial piping systems because of their superior ductility, weldability, and resistance to mechanical stress.
| ASTM A105 / A105M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Carbon Steel Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | Carbon Steel fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| Products | Size | |
|---|---|---|
| ASTM A105 Carbon Steel 90° Elbow | ASTM A105 Carbon Steel 45° Elbow | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| ASTM A105 Carbon Steel Forged Tee | ASTM A105 Carbon Steel Union | |
| ASTM A105 Carbon Steel Forged Cross | ASTM A105 Carbon Steel Insert | |
| ASTM A105 Carbon Steel Screwed Bushing | ASTM A105 Carbon Steel Threaded Pipe Nipple | |
| ASTM A105 Carbon Steel Forged Socket weld Cap | ASTM A105 Carbon Steel Screwed Coupling | |
| ASTM A105 Carbon Steel Forged Plug | ASTM A105 Carbon Steel Street Elbow | |
| Standard Code | Standard Name |
| ANSI ASME SA-105 | Forged fittings |
| ANSI ASME B16.11 | Socket-welding and Threaded forged fittings |
| MSS SP-79 | Socket-welding reducing Inserts |
| MSS SP-83 | Class 3000 steel socket-welding and threaded unions |
| MSS SP-95 | Swaged nipples and round plugs |
| MSS SP-97 | SW,TH and BW ends for integrally reinforced forged branch outlet |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Carbon steel forged fittings offer numerous advantages, including exceptional strength, durability, and reliability under high pressure and temperature conditions. Their ability to withstand extreme stress and corrosion makes them ideal for demanding industries like oil, gas, and construction. These fittings provide secure, leak-free connections, ensuring long-term performance and safety. The forging process enhances the material’s structural integrity, reducing the risk of failure. Additionally, carbon steel forged fittings are cost-effective, easy to maintain, and can be customized to meet specific project requirements, offering versatility and longevity in various applications.
Carbon Steel Forged Fittings from Harry Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Carbon Steel Forged Fitting are available at Harry Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@harryfittings.us.
Many different industries use carbon steel forged fittings in high-pressure piping systems. In the fields of power generation, refineries, chemical plants, oil and gas, and shipbuilding, they are perfect for joining and protecting pipelines. These fittings guarantee high-strength and leak-proof joints, particularly in systems with continuous vibration, pressure, and thermal cycling. Compressed air systems, cooling circuits, steam lines, and hydraulic systems are examples of common applications. They are also appropriate for underground and offshore installations due to their superior mechanical performance and resistance to corrosion. They are an essential part of effective fluid handling systems because of their strength and small size.
